Ford Econoline E350 (1997-1998) Keyless entry circuit

ANTI-THEFT SYSTEM ANTI-THEFT SYSTEM (SIDE DOOR COURTESY LAMP SWITCH) ANTI-THEFT SYSTEM HEADLIGHTS SYSTEM BATTERY SIDE/REAR DOOR LOCK CTRL BLK WIRE BLK/LT BLU WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BUTTON CONTACT (ATTACHED TO REAR OF "B" PILLAR) DK BLU WIRE DOOR LOCK CONTROL SIDE DOOR LOCK CTRL INTERIOR LAMPS OUTPUT DOOR LOCK CONTROL SWITCH EXTERIOR LIGHTS SYSTEM (MAIN LIGHT SWITCH) FUSE 4 FUSE 5 FUSE 3 GROUND BATTERY GROUND UNLOCK INPUT LOCK INPUT HEADLAMPS BATTERY RIGHT FRONT DOOR LOCK HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT AT ALL TIMES ENGINE COMPARTMENT FUSE BOX FUSE 16 HOT IN ACCY OR RUN HOT AT ALL TIMES I/P FUSE PANEL KICK PANEL) LEFT DOOR HANDLE SWITCH LEFT FRONT DOOR LOCK MOTOR LOCK LT BLU WIRE LT GRN WIRE MASTER WINDOW ORG/ WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/LT GRN WIRE PNK/ORG WIRE PNK/YEL WIRE PPL REAR DOOR LOCK MOTOR REAR POWER DOOR LOCK SWITCH RED WIRE RED/BLK WIRE RED/ORG WIRE REMOTE KEYLESS ENTRY MODULE (BEHIND LEFT "B" PILLAR) RIGHT DOOR HANDLE SWITCH RIGHT FRONT DOOR LOCK MOTOR RIGHT POWER DOOR LOCK/ WINDOW SWITCH RKE DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH) SIDE DOOR COURTESY SW IN SIDE DOOR LOCK MOTOR UNLOCK UNLOCK LOCK W/ SLIDING DOOR W/O SLIDING DOOR WHT WIRE WHT/LT BLU WIRE WHT/PPL WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
