Anti-lock brakes circuit for Ford Econoline E350 Super Duty (1999-2012)

1 2 3 4 5 6 7 8 9 10 11 DATA LINK CONN BPP SWITCH INPUT ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ABS IND. BATTERY JUNCTION BLK WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH) DK GRN WIRE DK GRN/YEL WIRE EXCEPT DIESEL EXCEPT DIESEL, EXCEPT STRIPPED CHASSIS EXCEPT STRIPPED CHASSIS FUSE 1 FUSE 11 GROUND VBATT GROUND VBATT BRAKE IND CTRL HOT AT ALL TIMES HOT IN RUN INSTRUMENT CLUSTER LEFT FRONT SENSOR (LOW) RIGHT FRONT SENSOR (LOW) REAR SENSOR (LOW) LEFT FRONT WHEEL SPEED SENSOR (BEHIND LEFT FRONT WHEEL) LOW BRAKE FLUID LEVEL/ PARK BRAKE IND LT BLU WIRE LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE MICROPROCESSOR NCA WIRE ORG/YEL WIRE PNK WIRE REAR AXLE SPEED SENSOR (UNDER REAR OF VEHICLE, MOUNTED ON DIFFERENTIAL) RED WIRE RED/PNK WIRE RIGHT FRONT WHEEL SPEED SENSOR (BEHIND RIGHT FRONT WHEEL) STRIPPED CHASSIS STRIPPED CHASSIS DIESEL TAN WIRE TAN/BLK WIRE TAN/LT GRN WIRE TAN/ORG WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
