All-wheel abs circuit for Ford Econoline E350 Super Duty (1999-2012)

1 2 3 4 5 6 7 8 9 10 11 ABS WARNING LAMP OUTPUT RELAY CTRL OUTPUT 1 2 POWER GROUND 14 15 16 17 18 19 20 21 22 23 24 POWER BPP SWITCH INPUT 4 WHEEL ANTI-LOCK 4-WHEEL ANTI- LOCK BRAKE SYSTEM RELAY (BEHIND CENTER OF DASH) ABS DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH) ACCY ANTI-LOCK BRAKE INDICATOR BATTERY JUNCTION BOX (IN LEFT FRONT OF ENGINE COMPARTMENT) BLK WIRE BRAKE PEDAL POSITION (BPP) SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) BRAKE WARN LAMP HIGH DATA LINK CONN BRAKE WARNING INDICATOR BRAKE WARNING LAMP LOW DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DK GRN WIRE DK GRN/YEL WIRE ELECTRONIC CRASH SENSOR (ECS) MODULE (BEHIND RIGHT SIDE OF DASH) FUSE 1 FUSE 11 FUSE 19 GRN WIRE HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR LOCK LT BLU WIRE LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE OFF OHM 1600 PNK WIRE PNK/LT GRN WIRE REAR AXLE SPEED SENSOR REAR SENSOR (HIGH) RIGHT FRONT SENSOR (HIGH) LEFT FRONT SENSOR (HIGH) REAR SENSOR (LOW) RIGHT FRONT SENSOR (LOW) LEFT FRONT SENSOR (LOW) RED WIRE RED/PNK WIRE RIGHT FRONT WHEEL SPEED SENSOR RUN WIRE TAN WIRE TAN/BLK WIRE TAN/LT GRN WIRE TAN/ORG WIRE VIO WIRE VIO/YEL WIRE WARNING SYSTEM WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
