Ford Econoline E350 Super Duty (1999-2012) ign multi- function switch wiring diagram
This page shows the only wiring diagram for the component.ign multi- function switch, which is found in the car Ford Econoline E350 Super Duty (1999-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ign multi- function switch wiring diagram (1 of 1)
ALL OTHERS
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX LEFT SIDE OF DASH, NEAR KICK PANEL)
CUT- AWAYS
ELECTRONIC FLASHER (BEHIND LEFT SIDE OF DASH)
FUSE 10
FUSE 11
FUSE 7
HAZARD
HAZARD SWITCH
HEAD OFF
HIGH MOUNTED STOP/ CARGO LAMP
HOT AT ALL TIMES
HOT IN RUN
IGN MULTI- FUNCTION SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER RIGHT TURN INDICATOR
LEFT FRONT PARK/ TURN LAMP
LEFT STOP/ PARK/ TURN LAMP
LEFT TURN INDICATOR
LICENSE LAMP
LT BLU WIRE
LT BLU/ WHT WIRE
LT GRN WIRE
LT GRN/RED WIRE
MAIN LIGHT SWITCH
NORMAL
ORG/ WIRE
PARK
PPL
RED WIRE
RED/LT GRN WIRE
RIGHT FRONT PARK/ TURN LAMP
RIGHT STOP/ PARK/ TURN LAMP
SOLID STATE
TAN WIRE
TO TRAILER/ CAMPER ADAPTER CIRCUIT (ELECTRONIC BRAKE)
TO TRAILER/CAMPER ADAPTER CIRCUIT (BATTERY JUNCTION BOX) (FUSES 5, 6)
TO TRAILER/CAMPER ADAPTER CIRCUIT (ELECTRONIC BRAKE)
TURN LEFT
TURN RIGHT
WHT LT GRN/ WIRE
WHT WIRE
WHT/LT BLU WIRE
Go to component -> Exterior lamps circuit -> IGN MULTI- FUNCTION SWITCH
