5.4l, a/t circuit, without torqshift for Ford Econoline E250 (1997-2012)

15 3 41 16 17 27 28 29 13 42 43 46 TSS SENSOR OSS SIG SIG RETURN 23 44 11 CAN- FEPS CAN+ 4.6L 5.4L BLK/WHT WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DK BLU/YEL WIRE DK GRN/WHT WIRE ELECTRONIC PRESSURE CONTROL SOLENOID ELECTRONIC THROTTLE CONTROL MOTOR (TOP FRONT OF ENGINE) ENGINE CONTROLS SYSTEM GRY WIRE GRY/RED WIRE GRY/WHT WIRE INSTRUMENT CLUSTER LT BLU/BLK WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/RED WIRE MASS AIR FLOW (MAF) SENSOR (AT CENTER OF ENGINE COMPT) ORG/BLK WIRE ORG/LT BLU WIRE ORG/YEL WIRE OUTPUT SHAFT SPEED (OSS) SENSOR (LEFT SIDE OF TRANSMISSION) PNK/LT GRN WIRE PNK/ORG WIRE RED WIRE RED/LT GRN WIRE SHIFT SOLENOIDS TAN/LT BLU WIRE TAN/LT GRN WIRE TFT SENSOR SIG EPC SOL SHIFT SOL A SHIFT SOL B TCC SOL THROTTLE POSITION SENSOR (TOP OF ENGINE, NEAR AIR INTAKE) TORQUE CONVERTER CLUTCH SOLENOID TPS POW TRANSMISSION FLUID TEMPERATURE SENSOR TURBINE SHAFT SPEED (TSS) SENSOR (LEFT SIDE OF TRANSMISSION) VIO WIRE VIO/ORG WIRE VIO/YEL WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/LT BLU WIRE YEL/WHT WIRE

24 45 8 REV LMP CTRL KAPWR BPP SW 27 1 4 5 6 16 17 18 28 47 48 49 50 10 OD CANCEL SW VSS APPA_+ 35 36 VPWR VPWR APPA_- APPB_+ APPB_- AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPT) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 23 BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) DK BLU/WHT WIRE DK GRN WIRE DK GRN/ORG WIRE ENDS IN HARNESS ENGINE CONTROLS SYSTEM FUSE 11 FUSE 2 FUSE 21 FUSE 27 FUSE 8 GROUND GROUND GROUND GROUND GROUND GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN OR START LT GRN/RED WIRE NCA WIRE OD OFF OVERDRIVE CANCEL SWITCH OVERHEAD CONSOLE (IF EQUIPPED) PCM POWER DIODE PCM POWER RELAY RED WIRE RED/LT GRN WIRE RED/YEL WIRE REVERSING LAMP RELAY TAN WIRE TAN/WHT WIRE TAN/YEL WIRE W/ ADVANCE TRAC W/ REMOTE KEYLESS ENTRY OR ADVANCE TRAC W/ STRIPPED CHASSIS WHT WIRE WHT/LT BLU WIRE WHT/RED WIRE YEL/BLK WIRE
