Wiring diagram engine performance 4.6ls for Ford Econoline E250 (1997-2012)

A/C SYSTEM A/C SYSTEM (ENGINE CONTROL HARNESS, NEAR BREAKOUT TO MASS AIRFLOW SENSOR) BATTERY JUNCTION BOX (LEFT FRONT OF ENGINE COMPT) BLK WIRE BLK/ WHT WIRE BLK/LT BLU WIRE BLK/WHT WIRE BRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH, NEAR LEFT KICK PANEL) COIL ON PLUG COIL ON PLUG 6 MIL DATA LINK (-) DATA LINK (+) DATA LINK CONNECTOR (PARTIAL) (LEFT SIDE OF DASH) 10 2 DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE ECT AIR CTRL SENS EVR SOL FUEL PUMP/ SENDER FUSE 20 FUSE 8 FUSE 4 GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START KNOCK SENSOR LT BLU/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE MAF FUEL PUMP MON A/C ON SIG MAF TFT MISFIRE SENS (+) MISFIRE SENS (-) NCA WIRE OD OFF ORG/BLK WIRE ORG/YEL WIRE OVERDRIVE CANCEL SWITCH PCM POWER DIODE PCM POWER RELAY FUSE 9 PNK/LT BLU WIRE PNK/LT GRN WIRE PNK/WHT WIRE PWR GND COIL ON PLUG 3 PWR GND GND COIL ON PLUG 1 COIL ON PLUG 5 RED WIRE RED/LT GRN WIRE SHIFT SOL A SHIFT SOL B TCIL IND FEPS (EPROM) TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/WHT WIRE TCIL LAMP TCS TO DTR SENSOR (DIAGRAM 4 OF 4) VIO WIRE VIO/ORG WIRE WHT WIRE WHT/LT GRN WIRE WHT/PNK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/WHT WIRE

BATTERY JUNCTION BOX (LEFT FRONT OF ENGINE COMPT) BLK/LT BLU WIRE BLK/WHT WIRE BRN WIRE BRN/LT GRN WIRE BRN/PNK WIRE BRN/WHT WIRE CRANKSHAFT POSITION SENSOR (LOWER RIGHT FRONT OF ENGINE) DELTA PRESSURE FEEDBACK EGR SENSOR (TOP LEFT REAR OF ENGINE) DK BLU WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE ENGINE COOLANT TEMPERATURE GAUGE FUEL LEVEL GAUGE FUEL PUMP RELAY FUEL TANK PRESSURE SENSOR (UNDER LEFT CENTER OF VEHICLE) FUSE 17 GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INLET AIR CONTROL SENSOR (LEFT FRONT OF ENGINE) INSTRUMENT CLUSTER INSTRUMENTATION ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT CENTER OF ENGINE) LT BLU/ORG WIRE MALFUNCTION INDICATOR MISFIRE SENSOR SHIELD NCA WIRE ORG/BLK WIRE ORG/YEL WIRE PNK/LT BLU WIRE PNK/LT GRN WIRE PNK/WHT WIRE POWER RED WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE TAN/LT BLU WIRE THROTTLE POSITION SENSOR (ON TOP OF ENGINE, NEAR AIR INTAKE) VIO/ORG WIRE WHT/RED WIRE YEL WIRE YEL/LT BLU WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/PNK WIRE BRN/WHT WIRE BRN/YEL WIRE DK BLU/YEL WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE EGR SOLENOID (ABOVE LEFT VALVE COVER, ON BRACKET) ELECTRONIC PRESSURE CONTROL SOLENOID EVAP CANISTER PURGE VALVE (IN CENTER REAR OF ENGINE COMPT) FUEL INJECTORS FUEL PUMP MODULE (IN FUEL TANK) GRN WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE IDLE AIR CONTROL VALVE (REAR OF ENGINE, NEAR AIR INTAKE) IN TRANSIT FUEL PUMP MODULE (CUTAWAYS) (UNDER VEHICLE, ON LEFT FRAME RAIL) INERTIA FUEL SHUT-OFF SWITCH (BEHIND RIGHT KICK PANEL) LT BLU WIRE LT BLU/ORG WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT LT LT NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE OUTPUT SHAFT SPEED SENSOR (LEFT SIDE OF TRANSMISSION) PNK/BLK WIRE PNK/LT BLU WIRE PNK/WHT WIRE RED WIRE RED/LT GRN WIRE RED/PNK WIRE SHIFT SOLENOIDS TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TORQUE CONVERTER CLUTCH SOLENOID TRANSMISSION FLUID TEMPERATURE SENSOR VIO/ORG WIRE VIO/YEL WIRE WHT WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/WHT WIRE

240 OHMS A/C SYSTEM BLK/LT BLU WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR (FRONT OF LEFT CYLINDER HEAD) CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH, NEAR LEFT KICK PANEL) DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU/YEL WIRE DK GRN WIRE DK GRN/VIO WIRE DPFE SENS CYL HEAD TEMP EVAP SOL VSS (+) A/C RELAY CTRL ENDS IN HARNESS FROM DTR SENSOR (DIAGRAM 1 OF 4) FUEL TANK PRESS FUSE 11 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR HEATER CTRL HOT AT ALL TIMES IAC SOL OSS (+) CYLINDER ID LT BLU WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT GRN/RED WIRE MAF SENS IN TP SENS IN MASS AIR FLOW SENSOR (TOP CENTER OF ENGINE COMPT) NCA WIRE OVER- HEAD CONSOLE PNK/LT BLU WIRE PNK/WHT WIRE PWR GND COIL ON PLUG 2 RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE SIG RTN BRAKE ON/OFF TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TAN/YEL WIRE VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR FUEL INJ 8 FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 VSS INPUT WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/PNK WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE
