Ford Econoline E250 (1997-2012) temperature function selector switch assembly blend door actuator wiring diagram
This page shows the only wiring diagram for the component.temperature function selector switch assembly blend door actuator, which is found in the car Ford Econoline E250 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
temperature function selector switch assembly blend door actuator wiring diagram (1 of 1)
ABS CONTROL MODULE
ACCESSORY DELAY RELAY
BLK/LT GRN WIRE
BRAKE SHIFT INTERLOCK
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DAYTIME RUNNING LIGHTS MODULE
DIGITAL AUXILIARY TRANSMISSION BATTERY RANGE RELAY (IF EQUIPPED) (DTR) SENSOR
DK BLU/ LT GRN WIRE
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
EXCEPT STRIPPED CHASSIS
EXCEPT TORQSHIFT
FROM FUSE 14 (DIAGRAM 3 OF 5)
FRONT PASSENGER WINDOW/DOOR LOCK SWITCH
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13 FUSE 19
FUSE 15
FUSE 18
FUSE 24
FUSE 3
FUSE 42
FUSE 6
FUSE 7
GRY/YEL WIRE
I/P BODY BUILDER CONNECTOR
IGNITION SWITCH
INSTRUMENT CLUSTER
LOCK
LOCK OFF
LT BLU/PNK WIRE
LT BLU/RED WIRE
LT GRN/VIO WIRE
MAIN LIGHT SWITCH
MASTER WINDOW/DOOR LOCK/UNLOCK SWITCH
MULTI- FUNCTION SWITCH
OFF
ORG/YEL WIRE
OVERHEAD CONSOLE
PNK/BLK WIRE
PNK/LT GRN WIRE
RADIO
RED WIRE
RED/ LT BLU WIRE
RED/LT BLU WIRE
RED/WHT WIRE
REVERSING LAMP RELAY
RUN WIRE
SIDE OF DASH)
STRIPPED CHASSIS
TEMPERATURE FUNCTION SELECTOR SWITCH ASSEMBLY BLEND DOOR ACTUATOR
TO FUSE 14 (DIAGRAM 5 OF 5)
TO FUSE 33 (DIAGRAM 5 OF 5)
TO FUSE 9 (DIAGRAM 5 OF 5)
TORQSHIFT
TRAILER ELECTRONIC BRAKE CONTROL CONNECTOR
W/ AUXILIARY BATTERY
W/ OVERHEAD CONSOLE
W/ POWER DOOR LOCKS
WHT/LT BLU WIRE
WHT/PNK WIRE
WHT/VIO WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (4 of 5) -> TEMPERATURE FUNCTION SELECTOR SWITCH ASSEMBLY BLEND DOOR ACTUATOR
