Ford Econoline E250 (1997-2012) spark plugs spark plugs spark plugs Wiring diagrams
This page contains all the electrical diagrams for the component. spark plugs spark plugs spark plugs, in which he is found in the car Ford Econoline E250 (1997-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram spark plugs spark plugs spark plugs (1 of 2)
360 648 1145 1146 570 527 (ENDS IN HARNESS)
AIR CONDITIONING SYSTEM
BATTERY JUNCTION
BLK/LT BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BOX (LEFT FRONT OF ENGINE COMPT)
BRN/PNK WIRE
CENTRAL JUNCTION BOX (BELOW LEFT SIDE OF DASH, NEAR LEFT KICK PANEL)
DATA LINK CONNECTOR (PARTIAL) (LEFT SIDE OF DASH)
DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION)
DK BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/YEL WIRE
DK GRN/VIO WIRE
DK GRN/YEL WIRE
EGR SOL CTRL NOT USED
F GAUGE SENDER PRGRM SIGNAL
FUSE 20 FUSE 8
FUSE 4
FUSE 9
GROUND GROUND IGN COIL 1 TCIL
GROUND IGN COIL
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IAT INPUT FUEL PUMP OUT A/C ON SIG IMRC
IGNITION COIL (LEFT FRONT OF ENGINE)
IGNITION TRANSFORMER CAPACITOR 1 (ATTACHED TO IGNITION COIL)
IMRC MONITOR
INSTRUMENT CLUSTER SYSTEM 29 107
KS +
LT BLU/BLK WIRE
LT GRN/RED WIRE
MAF RTN TFTS INPUT
NCA WIRE
OD CANCEL SW
OD OFF
ORG/BLK WIRE
ORG/YEL WIRE
OVERDRIVE CANCEL SWITCH
PCM POWER DIODE
PCM POWER RELAY
PNK/LT BLU WIRE
PNK/LT GRN WIRE
PNK/WHT WIRE
RED WIRE
RED/LT BLU WIRE
RED/LT GRN WIRE
SCP BUS SCP BUS
SPARK PLUGS SPARK PLUGS SPARK PLUGS
TAN/LT BLU WIRE
TAN/ORG WIRE
TAN/WHT WIRE
TO DTR SENSOR (DIAGRAM 4 OF 4)
TRANSMISSION CONTROL INDICATOR LAMP
VIO WIRE
VIO/ORG WIRE
WATER TEMP SENS
WHT/LT GRN WIRE
WHT/PNK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 4.2l (1 of 4) -> SPARK PLUGS SPARK PLUGS SPARK PLUGS
Wiring diagram spark plugs spark plugs spark plugs (2 of 2)
360 648 1145 1146 570 527 (ENDS IN HARNESS)
AIR CONDITIONING SYSTEM
BATTERY JUNCTION
BLK/LT BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BOX (LEFT FRONT OF ENGINE COMPT)
BRN/PNK WIRE
CENTRAL JUNCTION BOX (BELOW LEFT SIDE OF DASH, NEAR LEFT KICK PANEL)
DATA LINK CONNECTOR (PARTIAL) (LEFT SIDE OF DASH)
DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION)
DK BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/YEL WIRE
DK GRN/PNK WIRE
DK GRN/YEL WIRE
EGR SOL CTRL NOT USED
F GAUGE SENDER PRGRM SIGNAL
FUSE 20 FUSE 8
FUSE 4
FUSE 9
GROUND GROUND IGN COIL 1 TCIL
GROUND IGN COIL
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IAT INPUT FUEL PUMP OUT A/C ON SIG IMRC
IGNITION COIL (LEFT FRONT OF ENGINE)
IMRC MONITOR
INSTRUMENT CLUSTER SYSTEM 29 107
KS +
LT BLU/BLK WIRE
LT GRN/RED WIRE
MAF RTN TFTS INPUT
NCA WIRE
OD CANCEL SW
OD OFF
ORG/BLK WIRE
ORG/YEL WIRE
OVERDRIVE CANCEL SWITCH
PCM POWER DIODE
PCM POWER RELAY
PNK/LT BLU WIRE
PNK/LT GRN WIRE
PNK/WHT WIRE
RADIO CAPACITOR 1 (ATTACHED TO IGNITION COIL)
RED WIRE
RED/LT BLU WIRE
RED/LT GRN WIRE
SCP BUS SCP BUS
SPARK PLUGS SPARK PLUGS SPARK PLUGS
TAN/LT BLU WIRE
TAN/ORG WIRE
TAN/WHT WIRE
TO DTR SENSOR (DIAGRAM 4 OF 4)
TRANSMISSION CONTROL INDICATOR LAMP
VIO WIRE
VIO/ORG WIRE
WATER TEMP SENS
WHT/LT GRN WIRE
WHT/PNK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 4.2ls (1 of 4) -> SPARK PLUGS SPARK PLUGS SPARK PLUGS
