Ford Econoline E250 (1997-2012) lt grn Wiring diagrams

2/- 6.8L BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRN/ORG WIRE BRN/WHT WIRE CHT VSS PWR IN GND GND EPC OSS MAF TPS VREF SIG RTN BPP GND DIGITAL TRANSMISSION RANGE SENSOR DK BLU/YEL WIRE DK GRN/WHT WIRE FUEL TANK PRESSURE TRANSDUCER SENSOR FUSE 39 GND TCC KAPWR TSS GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 11 HOT IN RUN OR START FUSE 2 INSTRUMENT CLUSTER SYSTEM LT BLU/BLK WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/RED WIRE MAF TFT MAF VSS MULTIFUNCTION SWITCH, DEAVTIATOR SWITCH NCA WIRE OD OFF ORG/BLK WIRE ORG/YEL WIRE OTHERS OVERDRIVE CANCEL SWITCH OVERHEAD CONSOLE PNK/LT BLU WIRE POWERTRAIN CONTROL MODULE (PCM) (IN ENG COMPT, ON LEFT SIDE OF FIREWALL) RED WIRE RED/YEL WIRE SPEED CONTROL SERVO STRIPPED CHASSIS OTHERS TAN/LT BLU WIRE TAN/ORG WIRE TAN/WHT WIRE VEHICLE SECURITY MODULE VIO WIRE VIO/ORG WIRE VIO/YEL WIRE WHT WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE

BATTERY JUNCTION BOX BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BRN/ORG WIRE BRN/WHT WIRE COAST CLUTCH SOLENOID CYLINDER HEAD TEMPERATURE SENSOR (ON TOP FRONT OF LEFT CYLINDER HEAD) DK BLU/YEL WIRE DK GRN/WHT WIRE ELECTRONIC PRESSURE CONTROL SOLENOID ENGINE CONTROLS SYSTEM FUSE 21 FUSE 27 GASOLINE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) HOT IN RUN OR START CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 8 IGNITION COIL, RADIO NOISE CAPACITOR LT BLU/RED WIRE LT GRN WIRE NATURAL GAS VEHICLE ORG/BLK WIRE ORG/YEL WIRE OUTPUT SHAFT SPEED SENSOR (LEFT SIDE OF TRANSMISSION) PCM POWER DIODE PCM POWER RELAY RED WIRE SHIFT SOLENOID TAN/LT BLU WIRE THROTTLE POSITION SENSOR (TPS) (ON TOP OF ENGINE, NEAR AIR INTAKE) TORQUE CONVERTER CLUTCH SOLENOID SHIFT SOLENOID TRANSMISSION FLUID TEMPERATURE SENSOR TURBINE SHAFT SENSOR (AT LEFT SIDE OF TRANSMISSION) VIO/ORG WIRE VIO/YEL WIRE WHT WIRE WHT/LT BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE

2/- 6.8L BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRN/ORG WIRE BRN/WHT WIRE CHT VSS PWR IN GND GND EPC OSS MAF TPS VREF SIG RTN BPP GND DIGITAL TRANSMISSION RANGE SENSOR DK BLU/YEL WIRE DK GRN/WHT WIRE FUEL TANK PRESSURE TRANSDUCER SENSOR FUSE 39 GND TCC KAPWR TSS GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 11 HOT IN RUN OR START FUSE 2 INSTRUMENT CLUSTER SYSTEM LT BLU/BLK WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/RED WIRE MAF TFT MAF VSS MULTIFUNCTION SWITCH, DEAVTIATOR SWITCH NCA WIRE OD OFF ORG/BLK WIRE ORG/YEL WIRE OTHERS OVERDRIVE CANCEL SWITCH OVERHEAD CONSOLE PNK/LT BLU WIRE POWERTRAIN CONTROL MODULE (PCM) (IN ENG COMPT, ON LEFT SIDE OF FIREWALL) RED WIRE RED/YEL WIRE SPEED CONTROL SERVO STRIPPED CHASSIS OTHERS TAN/LT BLU WIRE TAN/ORG WIRE TAN/WHT WIRE VEHICLE SECURITY MODULE VIO WIRE VIO/ORG WIRE VIO/YEL WIRE WHT WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE

BATTERY JUNCTION BOX BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BRN/ORG WIRE BRN/WHT WIRE COAST CLUTCH SOLENOID CYLINDER HEAD TEMPERATURE SENSOR (ON TOP FRONT OF LEFT CYLINDER HEAD) DK BLU/YEL WIRE DK GRN/WHT WIRE ELECTRONIC PRESSURE CONTROL SOLENOID ENGINE CONTROLS SYSTEM FUSE 21 FUSE 27 GASOLINE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) HOT IN RUN OR START CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 8 IGNITION COIL, RADIO NOISE CAPACITOR LT BLU/RED WIRE LT GRN WIRE NATURAL GAS VEHICLE ORG/BLK WIRE ORG/YEL WIRE OUTPUT SHAFT SPEED SENSOR (LEFT SIDE OF TRANSMISSION) PCM POWER DIODE PCM POWER RELAY RED WIRE SHIFT SOLENOID TAN/LT BLU WIRE THROTTLE POSITION SENSOR (TPS) (ON TOP OF ENGINE, NEAR AIR INTAKE) TORQUE CONVERTER CLUTCH SOLENOID SHIFT SOLENOID TRANSMISSION FLUID TEMPERATURE SENSOR TURBINE SHAFT SENSOR (AT LEFT SIDE OF TRANSMISSION) VIO/ORG WIRE VIO/YEL WIRE WHT WIRE WHT/LT BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE

16 17 15 DRIVER DOOR AJAR SLIDING DOOR AJAR DOORS AJAR 23 22 MS CAN+ MS CAN- 5 10 RUN/START PWR GROUND BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FRONT PASSENGER WINDOW/DOOR LOCK SWITCH FUSE 14 FUSE 22 HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER LEFT FRONT DOOR AJAR SWITCH (AT LEFT KICK PANEL) LOCK LOGIC GROUND LR GRN WIRE LT BLU WIRE LT GRN WIRE MASTER WINDOW/ DOOR LOCK/UNLOCK SWITCH NCA WIRE PNK PNK WIRE PNK WIRE PNK/LT GRN WIRE PNK/YEL WIRE REAR DOORS DOOR AJAR RED WIRE RED/PNK WIRE RED/WHT WIRE RIGHT FRONT DOOR AJAR SWITCH (AT RIGHT KICK PANEL) RIGHT SIDE DOOR AJAR SWITCH (IN FRONT OF RIGHT SIDE DOOR) RIGHT SLIDING DOOR AJAR SWITCH (AT RIGHT "B" PILLAR) SWITCH (EXCEPT CUTAWAY) UNLOCK W/ HINGED CARGO DOOR W/ SLIDING CARGO DOOR WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 39 DK BLU WIRE DK GRN WIRE ELECTRONIC FLASHER MODULE (BEHIND LEFT SIDE OF DASH) ENDS IN HARNESS FUSE 10 FUSE 11 FUSE 7 GRN WIRE HAZARD SWITCH HEAD OFF HOT AT ALL TIMES HOT IN RUN INSTRUMENT CLUSTER LEFT TURN LEFT TURN IND LEFT TURN SIGNAL LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE MAIN LIGHT SWITCH MICROPROCESSOR MULTI- FUNCTION SWITCH ORG/ WIRE PARK RED WIRE RESISTOR RIGHT TURN RIGHT TURN IND RIGHT TURN SIGNAL SIDE MARKER STOP LAMPS TAN WIRE TO PARKING LAMP TRAILER TOW RELAY (DIAGRAM 2 OF 2) TO RIGHT TURN TRAILER TOW RELAY (DIAGRAM 2 OF 2) W/ REAR LIGHTS W/O REAR LIGHTS WHT WIRE WHT/LT BLU WIRE YEL WIRE

AUXILIARY BATTERY DIODE BATTERY JUNCTION BOX (LEFT FRONT FRONT OF OF ENG COMPT) AUXILIARY BATTERY RELAY (RIGHT FRONT OF ENGINE COMPT, NEAR BATTERY) AUXILIARY RELAY BOX 1 (AT LEFT SIDE OF ENGINE COMPT) BACK-UP LAMPS CIRCUIT BATTERY 2 BATTERY CHARGE TRAILER TOW RELAY BATTERY JUNCTION BOX (BJB) BATTERY JUNCTION BOX (BJB) (AT LEFT FRONT OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT) BLK WIRE BLU WIRE BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE ENDS IN HARNESS EXCEPT DIESEL, W/ AUXILIARY BATTERY EXCEPT DIESEL, W/ AUXILIARY BATTERY JUMPER FUSE 12 FUSE 15 FUSE 20 FUSE 24 FUSE 26 FUSE 8 HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR ACC LEFT TURN TRAILER TOW RELAY LT BLU WIRE LT GRN WIRE ORG/ WIRE PARKING LAMP TRAILER TOW RELAY PNK WIRE RED WIRE RED/YEL WIRE REVERSING LAMP TRAILER TOW RELAY RIGHT FRAME RAIL) RIGHT TURN TRAILER TOW RELAY TRAILER TOW CONNECTOR (7 PIN) (CLASS II) (AT RIGHT SIDE OF REAR BUMPER) VIO WIRE W/O AUXILIARY BATTERY WHT WIRE WHT/VIO WIRE YEL WIRE

A/C CLUTCH CYCLING PRESSURE SWITCH (RIGHT SIDE OF ENGINE COMPT) A/C CLUTCH FIELD COIL (ON LOWER RIGHT FRONT OF ENGINE) A/C CLUTCH RELAY A/C HIGH PRESSURE SWITCH (RIGHT SIDE OF ENGINE COMPT) A/C SW BLK WIRE BLK/YEL WIRE BRN WIRE BRN/LT GRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX BOX (CJB) (BEHIND LEFT SIDE OF DASH) CLUTCH CTRL DIESEL DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE DUAL PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT) ELECTRONIC FAN CLUTCH (DIESEL) (TOP FRONT OF ENGINE) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON UPPER LEFT FRONT OF ENGINE) (DIESEL) EXCEPT DIESEL EXCEPT DIESEL DIESEL EXCEPT STRIPPED CHASSIS FRONT FUNCTION SELECTOR SWITCH ASSEMBLY FSS FUNCTION SELECTOR SWITCH ASSEMBLY FUSE 13 FUSE 21 FUSE 23 FUSE 3 GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN RUN INPUT LT GRN WIRE MAX A/C MIX DEFROST OFF MODE SWITCH NCA WIRE NORM A/C FLOOR VENT MAX A/C MIX DEFROST OFF MODE SWITCH ORG/ WIRE PCM POWER RELAY PNK WIRE PNK/BLK WIRE PNK/YEL WIRE RED WIRE RED/ORG WIRE RELAY CTRL STRIPPED CHASSIS TEMPERATURE BLEND DOOR ACTUATOR (BEHIND RIGHT SIDE OF DASH) TEMPERATURE CONTROL POTENTIOMETER VENT NORM A/C FLOOR VIO WIRE VPWR WHT WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

AUXILIARY BLOWER MOTOR (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR SWITCH BLK WIRE BLOWER MOTOR RELAY BLOWER MOTOR RESISTOR (RIGHT SIDE OF ENGINE COMPT) BRN WIRE DK BLU WIRE FROM FUNCTION SELECTOR SWITCH (DIAGRAM 1 OF 2) FRONT BLOWER MOTOR (RIGHT REAR OF ENGINE COMPT) FRONT FUNCTION SELECTOR SWITCH ASSEMBLY MH ML HIGH LOW BLOWER MOTOR SWITCH FUSE 14 FUSE 17 HOT AT ALL TIMES LT BLU WIRE LT BLU/ORG WIRE LT GRN WIRE ML MH OFF ORG/ WIRE ORG/BLK WIRE PNK WIRE REAR A/C BLOWER SPEED RELAY 1 (IN LEFT REAR CORNER OF VEHICLE, ABOVE WHEELWELL) REAR A/C BLOWER SPEED RELAY 2 (IN LEFT REAR CORNER OF VEHICLE, ABOVE WHEELWELL) RED WIRE RED/ORG WIRE VAN, WAGON CUTAWAY WHT WIRE YEL WIRE

A/C DEMAND SIGNAL A/C ON INPUT SIGNAL BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/YEL WIRE BLOWER MOTOR RELAY CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CUSTOMER ACCESS FUSE 13 FUSE 17 HOT AT ALL TIMES HOT IN RUN LT GRN WIRE ORG/ WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT) RED WIRE RED/YEL WIRE TO BODY BUILDER CONNECTOR VIO WIRE YEL WIRE
