Headlights circuit, with stripped chassis for Ford Econoline E150 (1997-2012)

1 2 3 4 5 6 LO BEAM VBATT VPWR GND FPPWR BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT) BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 30 DAYTIME RUNNING LAMPS (DRL) MODULE (RIGHT FRONT OF ENGINE COMPARTMENT) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/ORG WIRE DRL EXCEPT DIESEL DIESEL FUSE 10 FUSE 15 FUSE 25 FUSE 3 FUSE 31 FUSE 6 GRY WIRE GRY/WHT WIRE HI FTP LO HI-BEAM IND HIGH BEAM, DRL HOT AT ALL TIMES HOT IN INSTRUMENT CLUSTER LOGIC GROUND LOW BEAM LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH OFF HEAD PARK ORG/ WIRE PARK BR SW PARKING BRAKE SWITCH (NEAR LEFT KICK PANEL) RED WIRE RED/BLK WIRE RUN WIRE STRIPPED CHASSIS CONNECTIONS TAN WIRE W/ PARKING AID WHT WIRE WHT/LT BLU WIRE YEL WIRE
