Ford Econoline E150 (1997-2012) xin gnd ain Wiring diagram
This page shows the only wiring diagram for the component.xin gnd ain, which is found in the car Ford Econoline E150 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram xin gnd ain (1 of 1)
ACCESSORY DELAY RELAY
AMP
AUTO DOWN SWITCH
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BRN YEL/ WIRE
CIRCUIT BREAKER
CONTROL
DN UP
DRIVER SIDE FRONT POWER WINDOW MOTOR (CENTER OF DRIVER'S DOOR)
DRV SW
GRN ORG/ WIRE
GRN WIRE
GRN/ BLU WIRE
GRN/BLU WIRE
HOT AT ALL TIMES
MASTER WINDOW ADJUST SWITCH
MICRO -
OUT
PASS SW
PASSENGER SIDE FRONT POWER WINDOW MOTOR (CENTER OF RIGHT FRONT DOOR)
PASSENGER SIDE WINDOW ADJUST SWITCH
RLY COIL
RLY DN CONTACT
VDD
VIO WIRE
WHT/ORG WIRE
XIN GND AIN
XOUT
YEL/VIO WIRE
Go to component -> Power windows circuit -> XIN GND AIN
