Ford Econoline E150 (1997-2012) upfitter switch Wiring diagrams
This page contains all the electrical diagrams for the component. upfitter switch, in which he is found in the car Ford Econoline E150 (1997-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram upfitter switch (1 of 2)
1 2 (W/O AERO HEADLAMPS) (W/ AERO HEADLAMPS)
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BREAKOUT TO FRONT
CIGAR LIGHTER
CLIMATE CONTROL ASSEMBLY
DATA LINK CONNECTOR (DLC)
GRY WIRE
IN-DASH COMPUTER
INSTRUMENT PANEL POWER POINT 1
INSTRUMENT PANEL POWER POINT 2
LEFT FRONT LEFT PARK/TURN HEADLAMP LAMP
LEFT FRONT SIDE LAMP HORN
PARKING BRAKE RESISTOR SWITCH
PASSENGER AIR BAG DEACTIVATION (PAD) SWITCH
PASSENGER SIDE DOOR LOCK SWITCH
RIGHT FRONT DOOR AJAR SWITCH
TEMPERATURE BLEND DOOR ACTUATOR
TRACTION CONTROL SWITCH
TRAILER BRAKE CONTROL FRONT (TBC) MODULE CIGAR LIGHTER
TRAILER BRAKE CONTROL TELEMATICS (TBC) MODULE MODULE
UPFITTER SWITCH
VIO WIRE
YEL WIRE
Go to component -> Ground distribution circuit (5 of 5) -> UPFITTER SWITCH
Wiring diagram upfitter switch (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLU/RED WIRE
BRN WIRE
EXCEPT STRIPPED CHASSIS
FROM FUSE 19 (DIAGRAM 4 OF 9) AB
FROM FUSE 20 (DIAGRAM 4 OF 9) AC
FROM FUSE 42 (DIAGRAM 4 OF 9)
FROM FUSE 44 (DIAGRAM 2 OF 9)
FROM FUSE 45 (DIAGRAM 2 OF 9) AA
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY/BRN WIRE
GRY/RED WIRE
SW 1
SW 2
SW 3
SW 4
UPFITTER RELAY 1
UPFITTER RELAY 2
UPFITTER RELAY 3
UPFITTER RELAY 4
UPFITTER SWITCH
VIO/GRN WIRE
VIO/GRY WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Power distribution circuit (9 of 9) -> UPFITTER SWITCH
