Ford Econoline E150 (1997-2012) steering position sensor Wiring diagram
This page shows the only wiring diagram for the component.steering position sensor, which is found in the car Ford Econoline E150 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering position sensor (1 of 1)
6.8L
ABS TEST CONNECTOR
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUDIO AUDIO CONTROL AMPLIFIER MODULE (ACM) (W/ NAVIGATION)
BATTERY JUNCTION BOX (BJB)
BATTERY SAVER RELAY
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN/VIO WIRE
CONTROL
EXCEPT 6.8L
EXCEPT STRIPPED CHASSIS
FROM
FROM FUSE 12 (DIAGRAM 2 OF 9)
FROM FUSE 22 FUSE 23 (DIAGRAM 5 OF 9)
FROM FUSE 27 (DIAGRAM ACCESSORY 6 OF 9) DELAY RELAY (EXCEPT STRIPPED CHASSIS)
FUEL PUMP MOTOR DIODE
FUEL PUMP RELAY BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 29 FUSE 30 FUSE 31
FUSE 33 FUSE 32
FUSE 38
FUSE 39
FUSE 40
FUSE 41
FUSE 47
FUSE 52
FUSE 53
FUSE 54
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
HIGH BEAM RELAY
HORN RELAY (EXCEPT STRIPPED CHASSIS)
IN-DASH COMPUTER
INSTRUMENT PANEL CLUSTER (IPC)
MASTER PASSENGER WINDOW SIDE WINDOW ADJUST ADJUST SWITCH SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RUN/START RELAY (MODIFIED VEHICLE)
STEERING POSITION SENSOR
STRIPPED CHASSIS
TELEMATICS MODULE (EXCEPT STRIPPED CHASSIS)
TO ACCESSORY DELAY RELAY (DIAGRAM 6 OF 9)
TO FUSE 34 (DIAGRAM 7 OF 9)
TO SPLICE 227
TRAILER BRAKE CONTROL (TBC) MODULE (EXCEPT STRIPPED CHASSIS)
VIO/ORG WIRE
VIO/RED WIRE
W/ ADVANCE TRAC
W/ CREW CHIEF
W/ REAR VIDEO CAMERA
W/O ADVANCE TRAC
WHT/BRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (6 of 9) -> STEERING POSITION SENSOR
