Ford Econoline E150 (1997-2012) selector neutral switch wiring harness, near breakout to Wiring diagram
This page shows the only wiring diagram for the component.selector neutral switch wiring harness, near breakout to, which is found in the car Ford Econoline E150 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector neutral switch wiring harness, near breakout to (1 of 1)
4.6L, 5.4L
6.8L
A/C CLUTCH RELAY
BATTERY JUNCTION
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLU/BRN WIRE
BLU/RED WIRE
BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BRAKE PEDAL POSITION SWITCH
BRN/RED WIRE
COIL ON COIL ON PLUG PLUG (COP) 2 (COP) 1
COIL ON COIL ON PLUG PLUG (COP) 5 (COP) 4
COIL ON COIL ON PLUG PLUG (COP) 7 (COP) 8
COIL ON IGNITION PLUG TRANSFORMER (COP) 6 CAPACITOR 1 (6.8L)
COIL ON PLUG (COP) 10 (6.8L)
COIL ON PLUG (COP) 3
COIL ON PLUG (COP) 9 (6.8L)
EVAP EGR CANISTER SYSTEM PURGE MODULE VALVE (ESM) (4.6L)
EXCEPT 6.8L
FROM
FROM FUSE 35 (DIAGRAM 2 OF 9)
FUSE 75
FUSE 76
FUSE 77
FUSE 78
FUSE 79
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/VIO WIRE
HEATED OXYGEN SENSOR
IGNITION TRANSFORMER CAPACITOR 1 (4.6L, 5.4L)
IGNITION TRANSFORMER CAPACITOR 2 (4.6L, 5.4L)
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR
OVERDRIVE TRANSMISSION CANCEL SWITCH (IF EQUIPPED)
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL MODULE (PCM) (4.6L, 5.4L)
POWERTRAIN CONTROL MODULE (PCM) (6.8L)
REVERSING LAMP RELAY
SELECTOR NEUTRAL SWITCH WIRING HARNESS, NEAR BREAKOUT TO
STRIPPED CHASSIS
STRIPPED CHASSIS, CUTAWAY
UNIVERSAL UNIVERSAL HEATED OXYGEN HEATED OXYGEN SENSOR SENSOR
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Power distribution circuit (8 of 9) -> SELECTOR NEUTRAL SWITCH WIRING HARNESS, NEAR BREAKOUT TO
