Ford Econoline E150 (1997-2012) rear doors lock switch Wiring diagram
This page shows the only wiring diagram for the component.rear doors lock switch, which is found in the car Ford Econoline E150 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear doors lock switch (1 of 1)
AUXILIARY BLOWER MOTOR RELAY
AUXILIARY BLOWER MOTOR SPEED RELAY
BLK WIRE
BLK/GRY WIRE
FUEL PUMP CONTROL MODULE
GRN WIRE
GRY WIRE
LEFT REAR PARK/STOP TURN LAMP
LEFT REVERSING LAMP
LICENSE PLATE LAMP
NCA WIRE
REAR DOORS DOOR AJAR SWITCH
REAR DOORS LOCK SWITCH
RIGHT FRONT RIGHT FRONT PARK/TURN SIDE LAMP LAMP
RIGHT HEADLAMP
RIGHT REAR PARK/STOP TURN LAMP
RIGHT REVERSING LAMP
SHIELD
VIDEO CAMERA
W/O AERO HEADLAMPS W/ AERO HEADLAMPS
Go to component -> Ground distribution circuit (4 of 5) -> REAR DOORS LOCK SWITCH
