Ford Econoline E150 (1997-2012) modified vehicle power Wiring diagram
This page shows the only wiring diagram for the component.modified vehicle power, which is found in the car Ford Econoline E150 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram modified vehicle power (1 of 1)
B+ (PARK OR HEAD)
BATTERY (B+)
BATTERY JUNCTION BOX (IN LEFT FRONT OF ENGINE COMPARTMENT)
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BRAKE SWITCH INPUT
BRN WIRE
CENTRAL JUNCTION BOX LEFT SIDE OF DASH, NEAR KICK PANEL)
CLASS 2 CLASS 1
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (ON LEFT SIDE OF TRANSMISSION)
DK BLU WIRE
DK GRN WIRE
EXTERIOR LIGHTS (BACKUP LAMPS CIRCUIT)
FROM EXTERIOR LAMPS CIRCUIT (BRAKE SWITCH)
FROM EXTERIOR LAMPS CIRCUIT (MAIN LIGHT SWITCH)
FROM EXTERIOR LIGHTS CIRCUIT
FUSE 12
FUSE 14
FUSE 15
FUSE 20
FUSE 22
FUSE 6 FUSE 5
GROUND
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN
HOT IN ACC OR RUN
INTERIOR LIGHTS
LT BLU WIRE
LT GRN WIRE
MODIFIED VEHICLE POWER
MULTI- FUNCTION SWITCH
NCA WIRE
NOT USED
ORG/ WIRE
PNK WIRE
PPL
RUN WIRE
TRAILER BACKUP LAMP RELAY
TRAILER BATTERY CHARGE RELAY
TRAILER CONNECTOR
TRAILER RUNNING LAMP RELAY
TRAILER/CAMPER ADAPTER (BELOW LEFT SIDE OF REAR BUMPER)
TRAILER/CAMPER ADAPTER (CLASS 2) (BELOW LEFT SIDE OF REAR BUMPER)
WHT WIRE
YEL WIRE
Go to component -> Trailer/camper adapter circuit -> MODIFIED VEHICLE POWER
