Ford Econoline E150 (1997-2012) low oil press/hi coolant temp ind Wiring diagrams

This page contains all the electrical diagrams for the component. low oil press/hi coolant temp ind, in which he is found in the car Ford Econoline E150 (1997-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram low oil press/hi coolant temp ind (1 of 3)

Wiring diagram low oil press/hi coolant temp ind for Ford Econoline E150 (1997-2012) (1 of 3)

Get access

1 2 4.2L/4.6L 5.4L/6.8L 1 2 7 4 ANTI-LOCK IND RELAY CTRL BRAKE SWITCH BRAKE IND 4 WHEEL ANTI- LOCK BRAKES MODULE (ON LEFT FRONT FRAME RAIL) 45 12 9 ECT SIGNAL FUEL SIGNAL 1 2 AIR BAG IND ANTI-LOCK BRAKE IND ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE WARNING IND CHARGE IND CNG GAS CONN A CONN B CONN C CRUISE CONTROL DAYTIME RUNNING LAMPS MODULE (IN RIGHT FRONT OF ENGINE COMPARTMENT, NEAR HORNS) DK GRN WIRE DK GRN/LT GRN WIRE DK GRN/YEL WIRE DUAL BRAKE WARNING SWITCH (BOTTOM OF MASTER CYLINDER) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE GAUGE ENGINE OIL PRESSURE GAUGE FASTEN SEATBELT IND FUEL PUMP MODULE (UNDER VEHICLE, IN FUEL TANK) FUSE 14 FUSE 2 FUSE 36 FUSE 4 GND IGNITION SWITCH GRY/BLK WIRE GRY/WHT WIRE HEADLIGHTS SYSTEM HIGH BEAM IND HOT AT ALL TIMES HOT IN PARK OR HEAD HOT IN RUN OR START INSTRUMENT CLUSTER INSTRUMENT ILLUMINATION INSTRUMENTATION ENGINE COOLANT TEMPERATURE SENSOR (ON FRONT OF ENGINE) INTERIOR FUSE PANEL (BEHIND LEFT SIDE OF DASH) LEFT TURN IND LOW OIL PRESS/HI COOLANT TEMP IND LT BLU WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/RED WIRE LT GRN/WHT WIRE MALFUNCTION (MIL) IND MIL IND OFF LOCK PARKING BRAKE SWITCH (NEAR LEFT KICK PANEL) PNK/LT GRN WIRE PNK/ORG WIRE POWERTRAIN CONTROL MODULE (NEAR BRAKE MASTER CYLINDER) PPL/WHT WIRE PPL/YEL WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE RELAY (BEHIND CENTER OF DASH) RIGHT TURN IND RUN WIRE SPEEDO- METER STARTING/ CHARGING SYSTEM 608 1044 SUPPLEMENTAL RESTRAINTS SYSTEM TACHO- METER TAN WIRE TAN/LT GRN WIRE VANS, WAGONS CUTAWAYS VEHICLE SPEED SENSOR (UNDER VEHICLE, ON LEFT SIDE OF TRANS) VOLTMETER VSS SIGNAL W/ DRL W/O DRL WARNING SYSTEMS 603 932 WHT WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> 4.2l, instrument cluster circuit -> LOW OIL PRESS/HI COOLANT TEMP IND
