Ford Econoline E150 (1997-2012) interior/ map switch and lamp Wiring diagrams
This page contains all the electrical diagrams for the component. interior/ map switch and lamp, in which he is found in the car Ford Econoline E150 (1997-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram interior/ map switch and lamp (1 of 3)
1 2 3 4 5 6 7 8 GROUND DOOR SW INPUT
BLK WIRE
BLK/LT BLU WIRE
CENTRAL JUNCTION BOX LEFT SIDE OF DASH, NEAR KICK PANEL)
CTSY LP CTRL
CUTAWAY MODELS
CUTAWAY ONLY
DOME
EXTERIOR LIGHTS SYSTEM (TRAILER/ CAMPER ADAPTER)
FUSE 4
HIGH MOUNTED STOPLAMP
HINGE DOOR SLIDING DOOR
HOT AT ALL TIMES
HOT IN RUN FUSE 24
IGNITION BATTERY
ILLUMINATED ENTRY MODULE (BEHIND CENTER OF DASH)
INTERIOR/ MAP SWITCH AND LAMP
LEFT
LEFT COURTESY LAMP SWITCH
LEFT DOOR HANDLE SWITCH
LT BLU WIRE
LT GRN WIRE
LT GRN/YEL WIRE
MAIN LIGHT SWITCH
PNK WIRE
PPL
RED WIRE
RIGHT
RIGHT COURTESY LAMP SWITCH
RIGHT DOOR HANDLE SWITCH
RIGHT LEFT
SIDE DOOR COURTESY LAMP SWITCH
TO HIGH MOUNTED STOP/CARGO LAMP, REAR COURTESY LAMP SWITCH (DIAGRAM 3 OF 3)
VANS/ WAGONS ONLY
VANS/WAGONS ONLY
W/ FULL HEADLINER
W/O FULL HEADLINER
W/O KEYLESS ENTRY VANS/WAGONS, CUTAWAYS
WARNING SYSTEMS (WARNING BUZZER MODULE)
WHT WIRE
WHT/LT BLU WIRE
WHT/PPL WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> INTERIOR/ MAP SWITCH AND LAMP
Wiring diagram interior/ map switch and lamp (2 of 3)
7 20 INT LPS OUT INT LPS OUT
8 11 21 22 23 26 GROUND DOOR HNDLE SW GROUND BATTERY GROUND
ANTI-THEFT SYSTEM
BLK WIRE
BLK/LT BLU WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX LEFT SIDE OF DASH, NEAR KICK PANEL)
DK BLU WIRE
DOME
FUSE 4
FUSE 5
HIGH MOUNTED STOPLAMP
HINGE DOOR
HOT AT ALL TIMES
INTERIOR/ MAP SWITCH AND LAMP
LEFT COURTESY LAMP SWITCH
LEFT DOOR HANDLE SWITCH
LT BLU WIRE
LT GRN WIRE
LT GRN/YEL WIRE
MAIN LIGHT SWITCH
ORG/ WIRE
PNK WIRE
RED WIRE
REMOTE KEYLESS ENTRY MODULE (BEHIND LEFT "B" PILLAR)
RIGHT COURTESY LAMP SWITCH
RIGHT DOOR HANDLE SWITCH
RIGHT LEFT
SIDE DOOR COURTESY LAMP SWITCH
SIDE DOOR CTSY SW
SLIDING DOOR
TO HIGH MOUNTED STOP/CARGO LAMP, REAR COURTESY LAMP SWITCH (DIAGRAM 3 OF 3)
W/ KEYLESS ENTRY VANS, WAGONS
W/FULL HEADLINER
W/O FULL HEADLINER
WARNING SYSTEMS (WARNING BUZZER MODULE)
WHT WIRE
WHT/LT BLU WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> INTERIOR/ MAP SWITCH AND LAMP
Wiring diagram interior/ map switch and lamp (3 of 3)
AUXILIARY BLOWER MOTOR RELAY
AUXILIARY HIGH BLOWER MOTOR RELAY
BLK WIRE
CARGO LAMP
DATA LINK CONNECTOR
ELECTRONIC CRASH SENSOR MODULE
HIGH MOUNTED STOPLAMP
INTERIOR SWITCH/ LAMP
INTERIOR/ MAP SWITCH AND LAMP
LEFT PARK/ STOP/TURN LAMP
LEFT REVERSING LAMP
LICENSE LAMP
LT BLU WIRE
LT GRN WIRE
NOT USED
RADIO
REAR INTERIOR/ MAP SWITCH, LAMP
REMOTE KEYLESS ENTRY MODULE
RIGHT PARK/ STOP/TURN LAMP
RIGHT REVERSING LAMP
VANS
W/ AUX A/C
W/O FULL HEADLINER W/ FULL HEADLINER
WAGONS
Go to component -> Ground distribution circuit (4 of 4) -> INTERIOR/ MAP SWITCH AND LAMP
