Ford Econoline E150 (1997-2012) ignition trans- former capacitor 1 (right front of Wiring diagram
This page shows the only wiring diagram for the component.ignition trans- former capacitor 1 (right front of, which is found in the car Ford Econoline E150 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition trans- former capacitor 1 (right front of (1 of 1)
BATTERY JUNCTION BOX (BJB) FUSE 78 (LEFT FRONT OF ENGINE COMPT)
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CHT
COIL ON COIL ON PLUG PLUG (COP) 3 (COP) 4
COIL ON PLUG (COP) 1 ENGINE)
COIL ON PLUG (COP) 2
COIL ON PLUG (COP) 5
COIL ON PLUG (COP) 6
COIL ON PLUG (COP) 7
COIL ON PLUG (COP) 8
DPFE
EVAPCP
EVR
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
IGNITION TRANS- FORMER CAPACITOR 1 (RIGHT FRONT OF
IGNITION TRANS- FORMER CAPACITOR 2 (LEFT FRONT OF ENGINE)
MAP VRSRTN CKP-
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
SOLID STATE
TACM+
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 4.6l (5 of 5) -> IGNITION TRANS- FORMER CAPACITOR 1 (RIGHT FRONT OF
