Ford Econoline E150 (1997-2012) fuel level vref Wiring diagram

BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/WHT WIRE BUS (-) BUS (+) CRANKSHAFT POSITION SENSOR (LOWER CENTER FRONT OF ENGINE) DIFFERENTIAL PRESSURE FEEDBACK EGR SENSOR (CALIFORNIA) (TOP LEFT SIDE OF ENGINE) DK BLU WIRE DK GRN/YEL WIRE EXCEPT STRIPPED CHASSIS FUEL LEVEL VREF FUEL PUMP FUEL PUMP DRIVER MODULE (UNDER REAR OF VEHICLE, NEAR TANK) FUEL PUMP RELAY FUEL TANK PRESSURE TRANSDUCER (IN FUEL TANK) FUSE 13 GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INJECTION PRESSURE SENSOR (FRONT OF LEFT CYLINDER BANK) INSTRUMENT CLUSTER LT BLU/ORG WIRE LT BLU/RED WIRE LT GRN/YEL WIRE MALFUNCTION INDICATOR LAMP ORG/BLK WIRE ORG/YEL WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/WHT WIRE RED WIRE RED/LT GRN WIRE RED/PNK WIRE STRIPPED CHASSIS TAN/LT BLU WIRE TAN/ORG WIRE THROTTLE POSITION SENSOR (ON TOP OF ENGINE, NEAR AIR INTAKE) VIO/ORG WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE
