Ford Econoline E150 (1997-2012) front function selector switch Wiring diagram
This page shows the only wiring diagram for the component.front function selector switch, which is found in the car Ford Econoline E150 (1997-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front function selector switch (1 of 1)
5.4L, 5.4L CNG, 6.8L
7.3L DI TURBO DIESEL
A/C CLUTCH CYCLING PRESSURE SWITCH (IN RIGHT FRONT OF ENGINE COMPARTMENT)
A/C CLUTCH SOLENOID (ON LOWER RIGHT FRONT OF ENGINE)
A/C CLUTCH SOLENOID (ON TOP LEFT FRONT OF ENGINE)
A/C COMPRESSOR CLUTCH DIODE (NEAR FRONT OF ENGINE)
A/C HIGH PRESSURE SWITCH (IN RIGHT FRONT OF ENGINE COMPARTMENT)
A/C ON INPUT SIGNAL
BLK WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX BOX (CJB) (LEFT SIDE OF DASH, NEAR KICK PANEL)
FRONT FUNCTION SELECTOR SWITCH
FRONT FUNCTION SELECTOR SWITCH ASSEMBLY
FUSE 13
HOT IN RUN
LT GRN WIRE
MAX A/C MIX DEFROST OFF MODE SWITCH
NORM A/C FLOOR VENT MAX A/C MIX DEFROST OFF MODE SWITCH
PNK WIRE
PNK/BLK WIRE
RED WIRE
TEMPERATURE CONTROL POTENTIOMETER
TO BLOWER MOTOR RELAY (DIAGRAM 2 OF 2)
VENT NORM A/C FLOOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> 5.4l, manual a/c circuit, without stripped chassis (1 of 2) -> FRONT FUNCTION SELECTOR SWITCH
