Ford Econoline E150 (1997-2012) 24 45 8 rev lmp ctrl kapwr bpp sw Wiring diagrams
This page contains all the electrical diagrams for the component. 24 45 8 rev lmp ctrl kapwr bpp sw, in which he is found in the car Ford Econoline E150 (1997-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
24 45 8 rev lmp ctrl kapwr bpp sw wiring diagram (1 of 3)
24 45 8 REV LMP CTRL KAPWR BPP SW
27 1 4 5 6 16 17 18 28 47 48 49 50 10 OD CANCEL SW VSS APPA_+
35 36 VPWR VPWR
APPA_- APPB_+
APPB_-
AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 23
BLK/LT BLU WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/ORG WIRE
ENDS IN HARNESS
ENGINE CONTROLS SYSTEM
FUSE 11
FUSE 2
FUSE 21
FUSE 27
FUSE 8
GROUND GROUND GROUND GROUND GROUND
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LT GRN/RED WIRE
NCA WIRE
OD OFF
OVERDRIVE CANCEL SWITCH
OVERHEAD CONSOLE (IF EQUIPPED)
PCM POWER DIODE
PCM POWER RELAY
RED WIRE
RED/LT GRN WIRE
RED/YEL WIRE
REVERSING LAMP RELAY
TAN WIRE
TAN/WHT WIRE
TAN/YEL WIRE
W/ ADVANCE TRAC
W/ REMOTE KEYLESS ENTRY OR ADVANCE TRAC
W/ STRIPPED CHASSIS
WHT WIRE
WHT/LT BLU WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> 4.6l, a/t circuit (2 of 2) -> 24 45 8 REV LMP CTRL KAPWR BPP SW
24 45 8 rev lmp ctrl kapwr bpp sw wiring diagram (2 of 3)
24 45 8 REV LMP CTRL KAPWR BPP SW
27 1 4 5 6 16 17 18 28 47 48 49 50 10 OD CANCEL SW VSS APPA_+
35 36 VPWR VPWR
APPA_- APPB_+
APPB_-
AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 23
BLK/LT BLU WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/ORG WIRE
ENDS IN HARNESS
ENGINE CONTROLS SYSTEM
FUSE 11
FUSE 2
FUSE 21
FUSE 27
FUSE 8
GROUND GROUND GROUND GROUND GROUND
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LT GRN/RED WIRE
NCA WIRE
OD OFF
OVERDRIVE CANCEL SWITCH
OVERHEAD CONSOLE (IF EQUIPPED)
PCM POWER DIODE
PCM POWER RELAY
RED WIRE
RED/LT GRN WIRE
RED/YEL WIRE
REVERSING LAMP RELAY
TAN WIRE
TAN/WHT WIRE
TAN/YEL WIRE
W/ ADVANCE TRAC
W/ REMOTE KEYLESS ENTRY OR ADVANCE TRAC
W/ STRIPPED CHASSIS
WHT WIRE
WHT/LT BLU WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> 5.4l, a/t circuit, without torqshift (2 of 2) -> 24 45 8 REV LMP CTRL KAPWR BPP SW
24 45 8 rev lmp ctrl kapwr bpp sw wiring diagram (3 of 3)
24 45 8 REV LMP CTRL KAPWR BPP SW
27 1 4 5 6 16 17 18 28 47 48 49 50 10 OD CANCEL SW VSS APPA_+
35 36 VPWR VPWR
APPA_- APPB_+
APPB_-
AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 23
BLK/LT BLU WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/ORG WIRE
ENDS IN HARNESS
ENGINE CONTROLS SYSTEM
FUSE 11
FUSE 2
FUSE 21
FUSE 27
FUSE 8
GROUND GROUND GROUND GROUND GROUND
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LT GRN/RED WIRE
NCA WIRE
OD OFF
OVERDRIVE CANCEL SWITCH
OVERHEAD CONSOLE (IF EQUIPPED)
PCM POWER DIODE
PCM POWER RELAY
RED WIRE
RED/LT GRN WIRE
RED/YEL WIRE
REVERSING LAMP RELAY
TAN WIRE
TAN/WHT WIRE
TAN/YEL WIRE
W/ ADVANCE TRAC
W/ REMOTE KEYLESS ENTRY OR ADVANCE TRAC
W/ STRIPPED CHASSIS
WHT WIRE
WHT/LT BLU WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> 5.4l, a/t circuit, with torqshift (2 of 2) -> 24 45 8 REV LMP CTRL KAPWR BPP SW
