Passive anti-theft circuit for Ford Contour I facelift (1997-2000)
Passive anti-theft circuit
2 10 DATA LINK CONNECTOR (LEFT OF STEERING COLUMN)
ALARM ON LED
ANTI-THEFT/CENTRAL LOCKING MODULE (BOTTOM OF RIGHT "A" PILLAR)
BATTERY JUNCTION BOX (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLOCK
FUSE 12
FUSE 30
GRY WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
NCA WIRE
ORG/BLU WIRE
PASSIVE ANTI- THEFT MODULE (BOTTOM OF RIGHT "A" PILLAR)
PASSIVE ANTI-THEFT TRANSCEIVER MODULE (TOP OF STEERING COLUMN)
SHORTING BAR CONNECTOR 2
STARTING SYSTEM
VIO/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
