Ford Contour I facelift (1997-2000) solid state bulb, gauge driver module wiring diagram
This page shows the only wiring diagram for the component.solid state bulb, gauge driver module, which is found in the car Ford Contour I facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
solid state bulb, gauge driver module wiring diagram (1 of 1)
2.5L 2.0L
2.5L ONLY
ABS FAULT IND
AIRBAG IND
ANTI-LOCK BRAKES SYSTEM
BATTERY JUNCTION BOX (BJB) (LEFT FRONT CORNER OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL SWITCH (IN LEFT REAR OF ENGINE COMPT)
BRAKE IND
CHARGE IND
CHECK ENGINE IND
COOLANT TEMPERATURE GAUGE
COOLANT TEMPERATURE SENSOR (LOWER LEFT SIDE OF ENGINE)
COOLANT TEMPERATURE SENSOR (UPPER REAR OF ENGINE)
CRUISE CONTROL, WARNING SYSTEMS
EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
FOG LAMPS IND
FUEL GAUGE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
HEADLIGHTS SYSTEM
HI-BEAM IND
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION
LEFT TURN IND
LOW COOLANT LEVEL IND
LOW FUEL IND
NCA WIRE
OD OFF
OFF
OIL PRESSURE IND
ORG/BLU WIRE
ORG/WHT WIRE
PARK BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
PCM POWER RELAY
RIGHT TURN IND
RUN WIRE
SEAT BELT IND
SHORTING BAR CONNECTOR 1 (BEHIND LEFT SIDE OF DASH)
SHORTING BAR CONNECTOR 2 (BEHIND CENTER OF DASH)
SHORTING BAR CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
SOLID STATE BULB, GAUGE DRIVER MODULE
SPEEDOMETER
STARTING/CHARGING SYSTEM WARNING SYSTEMS HEADLIGHTS SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM ANTI-LOCK BRAKES SYSTEM
TACHOMETER
TRACTION CONTROL IND
VEHICLE SPEED SENSOR (ON LOWER REAR OF TRANSAXLE)
VIO WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> SOLID STATE BULB, GAUGE DRIVER MODULE
