Ford Contour I (1994-1997) switch return wiring diagram
This page shows the only wiring diagram for the component.switch return, which is found in the car Ford Contour I (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
switch return wiring diagram (1 of 1)
1995 VFTC
A/T M/T
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BRAKE APPLIED IN
BRAKE ON/OFF SWITCH (TOP OF BRAKE PEDAL SUPPORT)
BRAKE SWITCH (TOP OF BRAKE PEDAL SUPPORT)
CLOCK SPRING ASSEMBLY
CLUTCH SWITCH (TOP OF CLUTCH PEDAL)
CRUISE CONTROL/HORN SWITCH
DEACTIVATION IN
GROUND
HOT AT ALL TIMES
HOT IN START OR RUN BACKUP LAMPS FUSE
IGNITION
INTERIOR FUSE PANEL STOP LAMPS FUSE
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/WHT WIRE
ORG/YEL WIRE
OTHER STANDARD
POWERTRAIN CONTROL MODULE
PPL/WHT WIRE
SPEED CONTROL CUTOUT RELAY (LEFT SIDE OF I/P)
SPEED CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT.)
SWITCH IN
SWITCH RETURN
TO HORN RELAY
VEHICLE SPEED SENSOR (LOWER REAR OF TRANSAXLE)
VSS IN
W/O TRACTION CONTROL W/TRACTION CONTROL
WHT WIRE
WHT/PPL WIRE
Go to component -> Cruise control circuit -> SWITCH RETURN
