Ford Club Wagon E350 (1996-1998) wire ends in harness Wiring diagram
This page shows the only wiring diagram for the component.wire ends in harness, which is found in the car Ford Club Wagon E350 (1996-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wire ends in harness (1 of 1)
B+ (PARK OR HEAD)
BLK WIRE
BLK/PNK WIRE
BRAKE SWITCH INPUT
BRN WIRE
CLASS 2 CLASS 1
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (LEFT SIDE OF TRANSMISSION)
DK BLU WIRE
DK GRN WIRE
ELECTRONIC BRAKE BATTERY (B+)
ENGINE COMPARTMENT FUSE BOX (LEFT FRONT OF ENGINE COMPARTMENT)
EXTERIOR LIGHTS (BACKUP LAMPS CIRCUIT)
FROM EXTERIOR LAMPS CIRCUIT (BRAKE SWITCH)
FROM EXTERIOR LAMPS CIRCUIT (MAIN LIGHT SWITCH)
FROM EXTERIOR LAMPS CIRCUIT (MAIN LIGHT SWITCH) FUSE 14
FROM EXTERIOR LIGHTS CIRCUIT (MULTI-FUNCTION SWITCH)
FUSE 12
FUSE 15
FUSE 20
FUSE 22
FUSE 6 FUSE 5
GROUND
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN
HOT IN ACC OR RUN
I/P FUSE PANEL (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MODIFIED VEHICLE POWER
NCA WIRE
NOT USED
ORG/ WIRE
PNK WIRE
PPL
RUN WIRE
TRAILER BACKUP LAMP RELAY (IN ENGINE COMPARTMENT FUSE BOX)
TRAILER BATTERY CHARGE RELAY (IN ENGINE COMPARTMENT FUSE BOX)
TRAILER CONNECTOR
TRAILER RUNNING LAMP RELAY (IN ENGINE COMPARTMENT FUSE BOX)
TRAILER/CAMPER ADAPTER (BELOW LEFT SIDE OF REAR BUMPER)
TRAILER/CAMPER ADAPTER (CLASS 2) (BELOW LEFT SIDE OF REAR BUMPER)
WHT WIRE
WIRE ENDS IN HARNESS
YEL WIRE
Go to component -> Trailer/camper adapter circuit -> WIRE ENDS IN HARNESS
