Ford Club Wagon E350 (1996-1998) trailer running lamp relay output Wiring diagram
This page shows the only wiring diagram for the component.trailer running lamp relay output, which is found in the car Ford Club Wagon E350 (1996-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer running lamp relay output (1 of 1)
AMBULANCE PACKAGE ONLY
B+ (PARK OR HEAD)
BACK-UP LAMP OUTPUT
BATTERY (B+)
BLK WIRE
BLK/PNK WIRE
BRAKE SWITCH INPUT
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DOME
DOME SWITCH INPUT
ELECTRONIC BRAKE (LEFT SIDE OF I/P, NEAR AIRBAG MODULE) BATTERY (B+)
ELECTRONIC BRAKE,
ENGINE COMPARTMENT FUSE PANEL (LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE COMPARTMENT FUSE PANEL (LEFT SIDE OF ENGINE COMPARTMENT) FUSE
FROM EXTERIOR LAMPS CIRCUIT (BRAKE ON/OFF (BOO) SWITCH)
FROM EXTERIOR LAMPS CIRCUIT (HEADLAMP SWITCH)
FROM EXTERIOR LIGHTS CIRCUIT (MULTI-FUNCTION SWITCH)
FUSE
FUSE 6
FUSE FUSE
GROUND
GROUND RIGHT TURN OUTPUT
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
INTERIOR FUSE PANEL (BEHIND LEFT SIDE OF I/P)
LEFT TURN OUTPUT
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MODIFIED VEHICLE POWER
NCA WIRE
ORG/ WIRE
PPL
RED WIRE
STARTING/ CHARGING SYSTEM (GENERATOR/ REGULATOR)
TRAILER CONNECTOR
TRAILER RUNNING LAMP RELAY OUTPUT
TRAILER/CAMPER ADAPTER CLASS 2
TRAILER/CAMPER ADAPTER CONNECTOR (BELOW LEFT SIDE OF BUMPER)
TRAILER/CAMPER ADAPTER CONNECTOR (BELOW LEFT SIDE OF REAR BUMPER)
W/ AUXILIARY BATTERY W/O AUXILIARY BATTERY
WHT WIRE
YEL WIRE
Go to component -> Trailer adapter/electronic brake circuit -> TRAILER RUNNING LAMP RELAY OUTPUT
