Ford Club Wagon E350 (1996-1998) speed control switch illum Wiring diagram
This page shows the only wiring diagram for the component.speed control switch illum, which is found in the car Ford Club Wagon E350 (1996-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speed control switch illum (1 of 1)
A/C ILLUMINATION LAMP
AUXILIARY A/C ILLUMINATION
BLK WIRE
CLOCK SPRING ASSEMBLY
CLOCK- SPRING ASSEM- BLY
DIMMER
EXCEPT CUTAWAY
FUSE 10
FUSE 3
FUSE 36
GROUND GROUND
HEAD
HOT AT ALL TIMES
HOT IN ACCY OR RUN
I/P FUSE PANEL
IGN
INSTRUMENT CLUSTER
LT BLU WIRE
LT BLU/RED WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
NCA WIRE
OFF HEAD PARK
OFF PARK
RADIO
RADIO BACKLIGHT ILLUMINATION
RED WIRE
SPEED CONTROL SWITCH ASSEMBLY
SPEED CONTROL SWITCH ILLUM
TAN/WHT WIRE
YEL/BLK WIRE
Go to component -> Instrument illumination circuit -> SPEED CONTROL SWITCH ILLUM
