Ford Club Wagon E350 (1996-1998) function selector switch illumination Wiring diagram
This page shows the only wiring diagram for the component.function selector switch illumination, which is found in the car Ford Club Wagon E350 (1996-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram function selector switch illumination (1 of 1)
4 WHEEL ANTI-LOCK BRAKES
4 WHEEL ANTI-LOCK BRAKES PROGRAMMABLE SPEEDOMETER/ ODOMETER MODULE (PSOM)
5.8L 49 STATES OVER 8600 GVW, 7.5L EXCEPT CALIFORNIA
ALL CUTAWAYS
ALL MODELS EXCEPT DIESEL VANS, WAGONS W/O PREMIUM SOUND, RABS
ALL VANS, WAGONS
AMPLIFIER MODULE
AUXILIARY HEATER BLOWER SWITCH OR AUXILIARY A/C-HEATER BLOWER SWITCH
BLEND DOOR ACTUATOR
BLK WIRE
CIGAR LIGHTER
DIESEL VANS, WAGONS W/O PREMIUM SOUND, RABS
DIESEL WARNING LAMPS DISPLAY MODULE
FRONT BLOWER SWITCH
FUEL PUMP/ SENDER
FUNCTION SELECTOR SWITCH ILLUMINATION
GASOLINE MODELS W/SPEED CONTROL PNK/ PNK/ WIRE
GRY WIRE
IN-TRANSIT FUEL-PUMP/ SENDER
INSTRUMENT CLUSTER
LT GRN WIRE
MODULE
NCA WIRE
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PROGRAMMABLE SPEEDOMETER/ ODOMETER MODULE (PSOM)
RADIO
REAR FUEL PUMP/ SENDER
RED WIRE
SPEED CONTROL SERVO/ AMPLIFIER ASSEMBLY POWERTRAIN CONTROL MODULE (PCM)
W/ AUXILIARY A/C
W/ PREMIUM SOUND
W/ PREMIUM SOUND W/
W/O PREMIUM SOUND
WHT WIRE
WIPER CONTROL MODULE
Go to component -> Ground distribution circuit (5 of 6) -> FUNCTION SELECTOR SWITCH ILLUMINATION
