Wiring diagram engine performance 7.3l di turbo diesels, federal (1 of 3) for Ford Cab & Chassis F350 (1996-1997)

A/T AUX RPM INPUT AUXILIARY POWERTRAIN CONTROL CONNECTOR (CENTER OF DASH) BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE PRESS SW BRAKE PRESSURE APPLIED SWITCH (NEAR LEFT FRONT RAIL) BRAKE WARNING IND BRN WIRE CLUTCH PEDAL POSITION SWITCH (TOP RIGHT SIDE OF BRAKE/CLUTCH PEDAL SUPPORT) CRUISE CONTROL SYSTEM DIESEL WARNING LAMPS DISPLAY "WAIT TO START" INDICATOR DK GRN/ ORG WIRE DK GRN/LT GRN WIRE DK GRN/ORG WIRE DLC EBP ENGINE COMPARTMENT FUSE BOX EOT FUSE 22 FUSE 8 FUSE 9 FUSE PANEL FUSE PANEL FUSE 3 GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN ENGINE COMPARTMENT FUSE BOX FUSE 5 HOT IN RUN OR START HOT IN RUN OR START HOT IN RUN FUSE 18 FUSE 17 IAT IDLE VALIDATION SW IDM RELAY IGNITION SWITCH INDICATOR SWITCH (FRONT OF TRANSFER CASE) INJECTION PRESSURE REGULATOR (IPR) (TOP CENTER OF ENGINE) INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM INTAKE AIR TEMPER- ATURE (IAT) SENSOR (TOP CENTER OF ENGINE) LOCK OFF LT BLU/ BLK WIRE LT BLU/BLK WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE M/T MALFUNCTION INDICATOR LAMP (MIL) MAP NCA WIRE ORG/BLK WIRE ORG/YEL WIRE PCM DLC PCM POWER DIODE PCM POWER RELAY PNK WIRE PNK/LT BLU WIRE PNK/LT GRN WIRE PNK/ORG WIRE POWER TAKE-OFF FEED PPL PPL 13 10 2 DATA LINK CONNECTOR (BEHIND LOWER CENTER OF DASH) PPL/LT BLU WIRE PPL/ORG WIRE PPL/WHT WIRE PPL/YEL WIRE PTO FEED PWR GND RED WIRE RED/LT GRN WIRE RED/ORG WIRE RED/YEL WIRE RUN WIRE SPEED CTRL GND TAN/LT BLU WIRE TAN/ORG WIRE TAN/WHT WIRE TCC TCS OR CPP TFT VSS GND WHT/BLK WIRE WHT/PPL WIRE YEL WIRE YEL/RED WIRE
