5.4l, back-up lamps circuit, a/t for Ford Cab & Chassis F350 Super Duty (1999-2012)
5.4l, back-up lamps circuit, a/t
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH)
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (ON LEFT SIDE OF TRANSMISSION)
ELECTROCHROMATIC INSIDE MIRROR UNIT
EXCURSION
FUSE 27
HOT IN RUN
LEFT REVERSING LAMP
LT BLU WIRE
PARKING AID MODULE (PAM) (AT RIGHT KICK PANEL)
PICKUP W/ CHASSIS CAB
PNK WIRE
REVERSING LAMP TRAILER TOW RELAY
RIGHT REVERSING LAMP
TO LEFT TAIL LAMPS
TO RIGHT TAIL LAMPS
W/ PARKING AID
