Power top/sunroof circuit for Ford C-MAX II facelift (2015-2019)

Power top/sunroof circuit

Get access

BACKWARD (OPEN) FORWARD (CLOSE) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) BRN WIRE FUSE 37 FUSE 81 GLASS ROOF PANEL BLIND MODULE GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED OPEN CLOSE OVERHEAD CONSOLE SWITCH ASSEMBLY REAR JUNCTION BOX (RJB) RED WIRE VBATT VIO WIRE VPWR WHT WIRE
