Electronic power steering circuit for Ford C-MAX II facelift (2015-2019)

Electronic power steering circuit

Get access

BATTERY JUNCTION BOX (BJB) BLK WIRE BLU WIRE BLU/GRY WIRE COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 26 GRN WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN+ I CAN - INSTRUMENT PANEL CLUSTER (IPC) MOTOR POWER STEERING CONTROL MODULE (PSCM) PWR GND VBATT VIO/GRY WIRE VPWR WHT WIRE WHT/BLU WIRE
