Car Wiring Diagrams for Passive anti-theft circuit for Ford C-MAX II facelift (2015-2019)

ANT BEHIND LEFT QUARTERPANEL) BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN/GRN WIRE BRN/WHT WIRE CENTER REAR OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM FUSE 2 FUSE 59 FUSE 81 GRN/ORG WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES HS CAN+ INSTRUMENT PANEL CLUSTER (IPC) INTERIOR LIGHT RELAY INTERNAL VPWR ANTENNA RKE GND RECEIVER K LINE LOGIC GND MICRO - MS CAN + PASSIVE ANTI-THEFT SYSTEM (PATS) CENTER ANTENNA PASSIVE ANTI-THEFT SYSTEM (PATS) FRONT ANTENNA PASSIVE ANTI-THEFT SYSTEM (PATS) REAR ANTENNA PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER PATS GND PATS RX PATS TX POWERTRAIN CONTROL MODULE (PCM) PWR RADIO FREQUENCY (RF) RECEIVER REAR JUNCTION BOX (RJB) RED WIRE REMOTE FUNCTION ACTUATOR (RFA) MODULE START/STOP) STARTING/CHARGING SYSTEM VBATT VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL/ORG WIRE
