Ford C-MAX II facelift (2015-2019) right footwell air discharge temperature sensor Wiring diagram

ASPIRATOR SENS AUTO AUTOLAMP/ SUNLOAD SENSOR BLK WIRE BLK/WHT WIRE BLOWER CONTROL BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BMRC BODY CONTROL MODULE (BCM) BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAN (+) COMPUTER DATA LINES SYSTEM DEFR A DEFR B DEFR C DEFR D DEFROST/REGISTER BLEND DOOR ACTUATOR DISC FLOOR L SENS DISC FLOOR R SENS DISC PANEL L SENS DISC PANEL R SENS EVAP EVAPORATOR TEMPERATURE SENSOR FOOTWELL VENT/DUCT BLEND DOOR ACTUATOR FUSE 71 FUSE 85 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HUMIDITY SENS IN-CAR SENS- IN-VEHICLE TEMPERATURE HUMIDITY/SENSOR L SUNL SENS L TEMP A L TEMP B L TEMP C L TEMP D LAMPS) LEFT CENTER REGISTER AIR DISCHARGE TEMPERATURE SENSOR LEFT FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR LEFT TEMPERATURE BLEND DOOR ACTUATOR LH OUT MICRO - MS CAN + PA/FL A PA/FL B PA/FL C PA/FL D R SUNL SENS R TEMP A R TEMP B R TEMP C R TEMP D RECIRC A RECIRC B RECIRC C RECIRC D RECIRCULATION BLEND DOOR ACTUATOR RH OUT RIGHT CENTER REGISTER AIR DISCHARGE TEMPERATURE SENSOR RIGHT FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR RIGHT TEMPERATURE BLEND DOOR ACTUATOR SEATS SYSTEM SENS SENS GND SIGRTN TEMP VBATT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR VREF WHT WIRE WHT/BLU WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
