Ford C-MAX II facelift (2015-2019) driver side interior lamp Wiring diagrams
This page contains all the electrical diagrams for the component. driver side interior lamp, in which he is found in the car Ford C-MAX II facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver side interior lamp wiring diagram (1 of 3)
AUTO DIMMING INTERIOR MIRROR
BATTERY CHARGER CONTROL MODULE (BCCM)
BATTERY ENERGY CONTROL MODULE (BECM)
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLOWER MOTOR CONTROL MODULE
BLU WIRE
CIGAR LIGHTER
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
DRIVER SIDE INTERIOR LAMP
FHEV
FLOOR CONSOLE CUP HOLDER AMBIENT LIGHTING LAMP
FRONT INTERIOR LAMP
FUEL DOOR INTERLOCK SWITCH
GLASS ROOF PANEL BLIND MODULE
GLOBAL POSITIONING SYSTEM MODULE (GPSM)
GLOVE COMPARTMENT LAMP
GRN WIRE
GRY WIRE
HIGH VOLTAGE BATTERY CHARGER COOLING FAN
HIGH VOLTAGE BATTERY COOLING FAN
LEFT FOOTWELL LAMP
LEFT REAR LAMP ASSEMBLY
LEFT VANITY MIRROR LAMP
OVERHEAD CONSOLE SWITCH ASSEMBLY
PASSENGER DOOR MODULE (PDM)
PASSENGER DOOR RELEASE LAMP
PASSENGER HEATED SEAT MODULE
PASSENGER POCKET MAP LAMP
PASSENGER REAR DOOR MODULE (PRDM)
PASSENGER SIDE FRONT SEAT CONTROL SWITCH
RADIO FREQUENCY (RF) RECEIVER
RAIN SENSOR
REAR FOOTWELL LAMP
REAR INTERIOR LAMP
RIGHT FOOTWELL LAMP
RIGHT FRONT DOOR LOCK SWITCH
RIGHT VANITY MIRROR LAMP
TELEMATIC CONTROL UNIT MODULE (TCU)
VIO WIRE
W/ AMBIENT LIGHTING
W/ HEATED SEATS
W/ INTELLIGENT ACCESS
W/ ROOF OPENING PANEL
W/O ROOF OPENING PANEL
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> DRIVER SIDE INTERIOR LAMP
driver side interior lamp wiring diagram (2 of 3)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CD SLOT ILLUMINATION
CLOCK SPRING (TOP OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
DRIVER SIDE INTERIOR LAMP
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT INTERIOR LAMP
FUSE 24
FUSE 3
FUSE 4
GRN WIRE
GRN/VIO WIRE
HEADLAMP SWITCH
HORN SWITCH
HOT AT ALL TIMES
HS CAN+
I CAN -
IGNITION SWITCH
ILLUM
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY
IP SW ILLUM
LEFT FRONT DOOR LOCK SWITCH
LEFT LOWER STEERING WHEEL SWITCH
LEFT UPPER STEERING WHEEL SWITCH
LIN
LIN (LSM)
LOGIC GND
MICRO -
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE SWITCH ASSEMBLY
PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR/ DEFROST SWITCH
PWR GND
RED WIRE
RIGHT FRONT DOOR LOCK SWITCH
RIGHT LOWER STEERING WHEEL SWITCH
RIGHT UPPER STEERING WHEEL SWITCH
STEERING ANGLE SENSOR MODULE (SASM)
SWITCH ILLUM.
TRANSMISSION CONTROL SWITCH
VBATT
VIO WIRE
VIO/GRY WIRE
W/ ROOF OPENING PANEL
W/O ROOF OPENING PANEL
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> DRIVER SIDE INTERIOR LAMP
driver side interior lamp wiring diagram (3 of 3)
ACTIVE GRILLE SHUTTER
BLK WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CABIN HEATER COOLANT DIVERTER VALVE
CABIN HEATER COOLANT PUMP
COIL ON PLUG (COP) 1
COIL ON PLUG (COP) 2
COIL ON PLUG (COP) 3
COIL ON PLUG (COP) 4
COOLANT WATER PUMP 1
DRIVER DOOR WINDOW CONTROL SWITCH
DRIVER SIDE INTERIOR LAMP
ELECTRIC EXHAUST GAS RECIRCULATION (EEGR) VALVE
ENGINE COOLING FAN RELAY
EVAPORATIVE EMISSION PURGE VALVE
FROM FUSE 34 (DIAGRAM 1 OF 6)
FROM FUSE 62 (DIAGRAM 4 OF 6)
FRONT INTERIOR LAMP
FUSE 32
FUSE 33
FUSE 35
FUSE 58
FUSE 59
FUSE 60
FUSE 63
GLOVE COMPART- MENT LAMP
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
IGNITION COIL 1
LEFT FOOTWELL LAMP
LEFT VANITY MIRROR LAMP
LUGGAGE COMPART- MENT LAMP
NCA WIRE
PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER
REAR INTERIOR LAMP
RIGHT FOOTWELL LAMP
RIGHT VANITY MIRROR LAMP
TO REAR JUNCTION BOX (RJB) (DIAGRAM 5 OF 6)
W/ ROOF OPENING PANEL
W/O AMBIENT LIGHTING
W/O ROOF OPENING PANEL
WHT/BRN WIRE
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit (3 of 6) -> DRIVER SIDE INTERIOR LAMP
