Fuel door release circuit for Ford C-MAX II (2010-2015)

34 20 19 FFDUC HS CAN + HS CAN - BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FFDUC FUEL DOOR INTERLOCK SWITCH (BEHIND RIGHT QUARTERPANEL) FUEL DOOR RELEASE RELAY FUEL FILLER DOOR LATCH MOTOR (BEHIND RIGHT QUARTERPANEL) FUSE 46 GRN/VIO WIRE HOT IN START OR RUN POWERTRAIN CONTROL MODULE (PCM) (FRONT OF LEFT FRONT WHEELWELL) WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL/BLU WIRE
