Ford C-MAX II (2010-2015) variable camshaft timing 11 Wiring diagrams

This page contains all the electrical diagrams for the component. variable camshaft timing 11, in which he is found in the car Ford C-MAX II (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram variable camshaft timing 11 (1 of 3)

Wiring diagram variable camshaft timing 11 for Ford C-MAX II (2010-2015)

Get access

BLK WIRE BRN/GRN WIRE CABIN HEATER COOLANT DIVERTER VALVE CABIN HEATER COOLANT PUMP COIL ON COIL ON PLUG PLUG (COP) 3 (COP) 4 COIL ON PLUG (COP) 2 COOLANT ACTIVE WATER GRILLE PUMP 1 SHUTTER DRIVER DOOR WINDOW CONTROL SWITCH DRIVER SIDE INTERIOR LAMP (W/ ROOF OPENING PANEL) ELECTRIC EXHAUST GAS RECIRCULATION (EEGR) VALVE ENGINE COOLING FAN RELAY EVAPORATIVE EMISSION CANISTER PURGE VALVE FROM FUSE 34 (DIAGRAM 1 OF 6) FROM FUSE 62 (DIAGRAM 4 OF 6) FRONT INTERIOR LAMP (W/O ROOF OPENING PANEL) FUSE FUSE 58 FUSE 59 FUSE 63 GLOVE COMPART- MENT LAMP GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY/ORG WIRE IGNITION COIL ON PLUG COIL 1 (COP) 1 LEFT FOOTWELL LAMP (W/O AMBIENT LIGHTING) LEFT VANITY MIRROR LAMP LUGGAGE LUGGAGE COMPART- COMPART- MENT MENT LAMP LAMP NCA WIRE OVERHEAD CONSOLE SWITCH ASSEMBLY PASSENGER SIDE INTERIOR LAMP (W/ ROOF OPENING PANEL) PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER REAR INTERIOR LAMP RIGHT FOOTWELL LAMP (W/O AMBIENT LIGHTING) RIGHT VANITY MIRROR LAMP SENSOR 1 TO REAR JUNCTION BOX (RJB) (DIAGRAM 5 OF 6) UNIVERSAL HEATED HEATED OXYGEN OXYGEN SENSOR SENSOR VARIABLE CAMSHAFT TIMING 11 WHT/BRN WIRE WHT/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Power distribution circuit (3 of 6) -> VARIABLE CAMSHAFT TIMING 11

Wiring diagram variable camshaft timing 11 (2 of 3)

Wiring diagram variable camshaft timing 11 for Ford C-MAX II (2010-2015)

Get access

BLK WIRE BLK/BLU WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL ASSEMBLY) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE COILS ON PLUG (COP) (TOP OF ENGINE) DIGITAL FP PWR FP RTN FPC FPM FUEL PUMP (FP) ASSEMBLY (IN FUEL TANK) FUEL PUMP CONTROL MODULE (FPCM) (BASE OF RIGHT "C" PILLAR) FUSE 46 (BASE OF LEFT "D" PILLAR) GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY/YEL WIRE HOT IN START OR RUN IGNITION COIL (LEFT SIDE OF ENGINE) INSTRUMENT CLUSTER SYSTEM NCA WIRE ORG/GRY WIRE POWER DISTRIBUTION SYSTEM REAR JUNCTION BOX (RJB) VARIABLE CAMSHAFT TIMING 11 VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR FUEL WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE

Go to component: -> Wiring diagram engine performance 2.0l flex fuel, fhev (7 of 8) -> VARIABLE CAMSHAFT TIMING 11

Wiring diagram variable camshaft timing 11 (3 of 3)

Wiring diagram variable camshaft timing 11 for Ford C-MAX II (2010-2015)

Get access

BLK WIRE BLK/BLU WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL ASSEMBLY) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE COILS ON PLUG (COP) (TOP OF ENGINE) DIGITAL FP PWR FP RTN FPC FPM FUEL PUMP (FP) ASSEMBLY (IN FUEL TANK) FUEL PUMP CONTROL MODULE (FPCM) (BASE OF RIGHT "C" PILLAR) FUSE 46 (BASE OF LEFT "D" PILLAR) GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY/YEL WIRE HOT IN START OR RUN IGNITION COIL (LEFT SIDE OF ENGINE) INSTRUMENT CLUSTER SYSTEM NCA WIRE ORG/GRY WIRE POWER DISTRIBUTION SYSTEM REAR JUNCTION BOX (RJB) VARIABLE CAMSHAFT TIMING 11 VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR FUEL WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE

Go to component: -> Wiring diagram engine performance 2.0l flex fuel, phev (7 of 8) -> VARIABLE CAMSHAFT TIMING 11
