Ford C-MAX II (2010-2015) turn lp vpwr mirr gnd Wiring diagram
This page shows the only wiring diagram for the component.turn lp vpwr mirr gnd, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn lp vpwr mirr gnd (1 of 1)
1 13 5 18 MS CAN+ MS CAN- TURN LP VPWR MIRR GND
2 13 VBATT GND
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRY WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FUSE 4
FUSE 5
GRN/BLU WIRE
GRN/BRN WIRE
GRY/ORG WIRE
HIGH MOUNTED STOPLAMP
HOT AT ALL TIMES
LEFT EXTERIOR MIRROR
LEFT LICENSE LAMP
LEFT REAR LAMP ASSEMBLY
MARKER
MS CAN - MS CAN +
NCA WIRE
PASSENGER DOOR MODULE (PDM)
POSITION
REAR JUNCTION BOX (RJB) (BASE OF LEFT "D" PILLAR)
RED WIRE
REVERSE
RIGHT EXTERIOR MIRROR
RIGHT LICENSE LAMP
STOP
TURN
TURN LP VPWR MIRR GND
VBATT GND
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
W/ POWER LIFTGATE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component: -> Exterior lamps circuit (2 of 2) -> TURN LP VPWR MIRR GND
