Ford C-MAX II (2010-2015) switch illum. Wiring diagram
This page shows the only wiring diagram for the component.switch illum., which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch illum. (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH)
BRN WIRE
CLOCKSPRING (TOP OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
DRIVER HEATED SEAT SWITCH (W/ HEATED SEATS)
FUSE
FUSE 24
GRN WIRE
GRN/VIO WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
HS CAN+
I CAN -
IGNITION SWITCH
ILLUM
INSTRUMENT PANEL DIMMER
IP SW ILLUM
LEFT LOWER STEERING WHEEL
LEFT RIGHT FRONT DOOR LOCK SWITCH FRONT DOOR LOCK SWITCH
LEFT UPPER STEERING WHEEL SWITCH
LIN
LIN (LSM)
LOGIC GND
MICRO -
NAVIGATION SYSTEM DISPLAY MODULE
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE SWITCH ASSEMBLY
PASSENGER HEATED SEAT SWITCH (W/ HEATED SEATS)
PWR GND
RED WIRE
RIGHT LOWER STEERING WHEEL
RIGHT UPPER STEERING WHEEL SWITCH
STEERING ANGLE SENSOR MODULE
SWITCH
SWITCH ILLUM.
TRANSMISSION CONTROL SWITCH
V BATT
VBATT
VIO/ BLK WIRE
VIO/GRY WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> SWITCH ILLUM.
