Ford C-MAX II (2010-2015) sunload sensor (top right Wiring diagram
This page shows the only wiring diagram for the component.sunload sensor (top right, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunload sensor (top right (1 of 1)
AIR CONDITIONING SYSTEM
AUTOLAMPS SENSOR
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH)
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP RELAY
FOG LAMP RELAY HI BEAM RELAY
FUSE
FUSE 24
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HEADLAMP SWITCH
HIGH BEAM RELAY
HOT AT ALL TIMES
HS CAN+
INSTRUMENT PANEL CLUSTER
L SUNL SNSR
LEFT FRONT FOG LAMP
LEFT HEADLAMP ASSEMBLY
LEFT LOW BEAM
LIN
LIN (LSM)
LIN 1
LOGIC GND
MICRO -
MS CAN +
MULTI- FUNCTION SWITCH
PARKING BRAKE WARNING INDICATOR SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY)
PRK BRK SW
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT LOW BEAM
RSUNL SNSR
SIDE OF DASH)
SIGRTN
SNSR GND
STEERING ANGLE SENSOR MODULE (SASM)
SUNLOAD SENSOR (TOP RIGHT
V BATT
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component: -> Headlights circuit -> SUNLOAD SENSOR (TOP RIGHT
