Ford C-MAX II (2010-2015) (rear axle wiring harness, near breakout to fuel Wiring diagram

ACC/ START/ BATTERY CHARGER CONTROL MODULE (BCCM) (PHEV) BATTERY ENERGY CONTROL MODULE (BECM) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLU/GRY WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH) BRN WIRE BRN/YEL WIRE EVAPORATIVE EMISSION (EVAP) LEAK DETECTION CONTROL MODULE FHEV FROM FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 6) FROM SPLICE 124 (DIAGRAM 2 OF 6) FRONT WASHER RELAY FUEL DOOR RELEASE RELAY FUEL PUMP FOG LAMP RELAY RELAY FUEL TANK ISOLATION VALVE (PHEV) FUSE FUSE 46 FUSE FUSE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE HIGH BEAM RELAY IGNITION SWITCH ILLUM KEY IN IGN SW KEY-IN IGNITION SWITCH LOCK MICRO - NCA WIRE OFF OFF OFF POWERTRAIN CONTROL MODULE (PCM) REAR WASHER RELAY RED WIRE REMOTE FUNCTION ACTUATOR (RFA) MODULE REVERSING LAMP RELAY RUN WIRE START/ STOP SW 1 START/ STOP SW 2 TANK UNIT) TRANSMISSION POWERTRAIN CONTROL CONTROL SWITCH MODULE (PCM) (TCS) VAPOR MANAGEMENT VALVE (FHEV) VIO/GRN WIRE VIO/ORG WIRE VIO/RED WIRE W/O INTELLIGENT W/ INTELLIGENT ACCESS ACCESS WHT/BRN WIRE WHT/RED WIRE YEL WIRE
