Ford C-MAX II (2010-2015) power liftgate striker release motor switch Wiring diagram
This page shows the only wiring diagram for the component.power liftgate striker release motor switch, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power liftgate striker release motor switch (1 of 1)
BASE
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
DRIVE SIDE FRONT SEAT CONTROL SWITCH
DRIVER DOOR MODULE (DDM)
DRIVER DRIVER DOOR POCKET RELEASE MAP LAMP LAMP
DRIVER REAR DOOR MODULE (DRDM)
FUEL FILLER DOOR LATCH MOTOR
GRN WIRE
HANDSFREE LIFTGATE ACTUATOR MODULE
HEATED REAR WINDOW ELEMENT
HIGH MOUNTED STOP LAMP
LEFT FRONT DOOR LOCK SWITCH
LEFT LICENSE LAMP
LEFT REAR LAMP ASSEMBLY
LIFTGATE/ LUGGAGE COMPARTMENT LID LATCH
LUGGAGE RIGHT COMPARTMENT REAR POWER LAMP OUTLET ASSEMBLY SOCKET
PARKING AID MODULE
POWER LIFTGATE STRIKER RELEASE MOTOR SWITCH
REAR GATE TRUNK MODULE (RGTM)
REAR POWER LIFTGATE SWITCH
REAR WINDOW WIPER MOTOR
REMOTE FUNCTION ACTUATOR (RFA) MODULE
RIGHT LICENSE LAMP
RIGHT REAR LAMP ASSEMBLY
VIO WIRE
W/ INTELLIGENT ACCESS
W/ POWER LIFTGATE
W/O HEATED SEATS
W/O POWER LIFTGATE
WHT WIRE
Go to component: -> Ground distribution circuit (4 of 4) -> POWER LIFTGATE STRIKER RELEASE MOTOR SWITCH
