Ford C-MAX II (2010-2015) passenger side instrument panel speaker Wiring diagrams
This page contains all the electrical diagrams for the component. passenger side instrument panel speaker, in which he is found in the car Ford C-MAX II (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger side instrument panel speaker (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 BATT ANT PWR
1 2 3 4 LF SPKR + LR SPKR + RF SPKR + RR SPKR +
5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 MIC 1 + MIC 2 +
ACTIVE NOISE CONTROL MICROPHONE-1 (ABOVE DRIVER'S DOOR IN ROOF)
AMP ENABLE IP SPKR- LR SPKR - LF SPKR - RF SPKR - RR SPKR - GND I CAN + I CAN -
ANTENNA
AUDIO CONTROL MODULE
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COAXIAL CABLE COAXIAL CABLE
COAXIAL CABLE COAXIAL CABLE SDARS AM/FM
COMPUTER DATA LINES SYSTEM
DIGITAL AUDIO CONTROL MODULE (RIGHT SIDE OF DASH)
DRIVER SIDE INSTRUMENT PANEL SPEAKER
GRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HARNESS, NEAR BREAKOUT
HOT AT ALL TIMES REAR JUNCTION BOX (BASE OF LEFT "D" PILLAR) FUSE 22
I CAN + LF SPKR - LR SPKR - RF SPKR - RR SPKR - MIC 1 - MIC 2 -
I CAN -
INSTRUMENT PANEL CENTER SPEAKER (9 SPEAKERS)
LEFT FRONT DOOR SPEAKER
LF SPKR - LR SPKR - RF SPKR - RR SPKR -
MIC -
MIC 3 -
NCA WIRE
PASSENGER SIDE INSTRUMENT PANEL SPEAKER
SHIELD IP SPKR + LR SPKR + LF SPKR + RF SPKR + RR SPKR + 20 21 22 23 24
SOLID STATE
VIO/GRY WIRE
VIO/ORG WIRE
W/ SATELLITE RADIO
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit (1 of 2) -> PASSENGER SIDE INSTRUMENT PANEL SPEAKER
Wiring diagram passenger side instrument panel speaker (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 BATT ANT PWR
1 2 3 4 LF SPKR + LR SPKR + RF SPKR + RR SPKR +
5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 MIC 1 + MIC 2 +
ACTIVE NOISE CONTROL MICROPHONE-1 (ABOVE DRIVER'S DOOR IN ROOF)
AMP ENABLE IP SPKR- LR SPKR - LF SPKR - RF SPKR - RR SPKR - GND I CAN + I CAN -
ANTENNA
AUDIO CONTROL MODULE
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COAXIAL CABLE COAXIAL CABLE
COAXIAL CABLE COAXIAL CABLE SDARS AM/FM
COMPUTER DATA LINES SYSTEM
DIGITAL AUDIO CONTROL MODULE (RIGHT SIDE OF DASH)
DRIVER SIDE INSTRUMENT PANEL SPEAKER
GRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HARNESS, NEAR BREAKOUT
HOT AT ALL TIMES REAR JUNCTION BOX (BASE OF LEFT "D" PILLAR) FUSE 22
I CAN + LF SPKR - LR SPKR - RF SPKR - RR SPKR - MIC 1 - MIC 2 -
I CAN -
INSTRUMENT PANEL CENTER SPEAKER (9 SPEAKERS)
LEFT FRONT DOOR SPEAKER
LF SPKR - LR SPKR - RF SPKR - RR SPKR -
MIC -
MIC 3 -
NCA WIRE
PASSENGER SIDE INSTRUMENT PANEL SPEAKER
SHIELD IP SPKR + LR SPKR + LF SPKR + RF SPKR + RR SPKR + 20 21 22 23 24
SOLID STATE
VIO/GRY WIRE
VIO/ORG WIRE
W/ SATELLITE RADIO
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Premium radio circuit (1 of 2) -> PASSENGER SIDE INSTRUMENT PANEL SPEAKER
