Ford C-MAX II (2010-2015) left right front door lock switch front door lock switch Wiring diagram

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU/GRY WIRE BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH) BRN WIRE CLOCKSPRING (TOP OF STEERING COLUMN) COMPUTER DATA LINES SYSTEM DRIVER HEATED SEAT SWITCH (W/ HEATED SEATS) FUSE FUSE 24 GRN WIRE GRN/VIO WIRE HEADLAMP SWITCH HOT AT ALL TIMES HS CAN+ I CAN - IGNITION SWITCH ILLUM INSTRUMENT PANEL DIMMER IP SW ILLUM LEFT LOWER STEERING WHEEL LEFT RIGHT FRONT DOOR LOCK SWITCH FRONT DOOR LOCK SWITCH LEFT UPPER STEERING WHEEL SWITCH LIN LIN (LSM) LOGIC GND MICRO - NAVIGATION SYSTEM DISPLAY MODULE NCA WIRE ORG/ WIRE OVERHEAD CONSOLE SWITCH ASSEMBLY PASSENGER HEATED SEAT SWITCH (W/ HEATED SEATS) PWR GND RED WIRE RIGHT LOWER STEERING WHEEL RIGHT UPPER STEERING WHEEL SWITCH STEERING ANGLE SENSOR MODULE SWITCH SWITCH ILLUM. TRANSMISSION CONTROL SWITCH V BATT VBATT VIO/ BLK WIRE VIO/GRY WIRE WHT WIRE WHT/ BLK WIRE WHT/BLU WIRE WHT/ORG WIRE YEL WIRE
