Ford C-MAX II (2010-2015) hot w/ ignition relay energized Wiring diagram

12 13 MS CAN + MS CAN - COMPUTER DATA LINES SYSTEM 2 3 4 5 1 14 LIN 1 WIPER LIMP HOME HS CAN + HS CAN - VBATT PWR GND BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH) BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FRONT WASHER RELAY FRT WIPER HI/LO CTRL FRT WIPER ON/OFF CTRL FUSE 14 FUSE 24 FUSE 18 FUSE 62 FUSE 72 FUSE 77 FUSE 82 GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN+ INSTRUMENT PANEL CLUSTER (IPC) INTERIOR LIGHT RELAY LIN LIN 1 LIN 8 (RSM) MICRO - ORG/ WIRE PRK POS RAIN SENSOR (IF EQUIPPED) (TOP CENTER OF WINDSHIELD) REAR JUNCTION BOX (RJB) (BASE OF LEFT "D" PILLAR) REAR WASHER RELAY REAR WINDOW WIPER MOTOR (CENTER OF LIFTGATE) REAR WIPER RELAY RED WIRE RLY CTRL REAR WIPER SASM SPLY STEERING ANGLE SENSOR MODULE (SASM) VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR W/ POWER LIFTGATE W/O POWER LIFTGATE WHT WIRE WHT/BLU WIRE WHT/RED WIRE WINDSHIELD WASHER PUMP (IN WASHER FLUID RESERVOIR) WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT) WIPER HIGH/LOW RELAY WIPER LIMP HOME WIPER RUN/PARK RELAY WIPER/WASHER SWITCH YEL WIRE
