Ford C-MAX II (2010-2015) high voltage battery service disconnect (left front Wiring diagram
This page shows the only wiring diagram for the component.high voltage battery service disconnect (left front, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high voltage battery service disconnect (left front (1 of 1)
BLU/WHT WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA
CONT PWR EN
CS RTN
CS VREF
CTO
DC/DC CONVERTER MODULE (LEFT SIDE OF HIGH VOLTAGE BATTERY COMPT)
DCDC WKUP
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/YEL WIRE
HIGH VOLTAGE BATTERY
HIGH VOLTAGE BATTERY SERVICE DISCONNECT (LEFT FRONT
HS CAN+
HV BATT -
LINES SYSTEM
MC-CTRL
MODULE C/ TRANSMISSION CONTROL MODULE (ON TRANSMISSION)
OF HIGH VOLTAGE BATTERY COMPT)
ORG/ WIRE
POSITIVE PACK RELAY
PRC CTRL
RED WIRE
SECONDARY ON BOARD DIAGNOSTIC
TCMRC
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component: -> Wiring diagram engine performance 2.0l flex fuel, fhev (4 of 8) -> HIGH VOLTAGE BATTERY SERVICE DISCONNECT (LEFT FRONT
