Ford C-MAX II (2010-2015) fuse 24 fuse 13 Wiring diagram
This page shows the only wiring diagram for the component.fuse 24 fuse 13, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 24 fuse 13 (1 of 1)
AAT
AAT SENSOR RIGHT EXTERIOR MIRROR
ACLP
AIR CONDITIONING (A/C) PRESSURE TRANSDUCER (ON A/C COMPRESSOR)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CABIN HEATER COOLANT PUMP (PHEV) (RIGHT REAR OF ENGINE COMPT)
CHT
COMPUTER DATA LINES SYSTEM
CYLINDER HEAD TEMPERATURE (CHT) SENSOR (TOP OF ENGINE)
ENGINE COOLING FAN RELAY
FCV
FUSE
FUSE 10
FUSE 24 FUSE 13
FUSE 29
FUSE 32
FUSE 35
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HCSO
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
HS CAN+
LIN
NCA WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM) (FRONT OF LEFT FRONT WHEELWELL)
PWM
PWM V POWER GND
RED WIRE
SIG RTN
SIGRTN
TCM POWER RELAY
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VREF
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component: -> Automatic a/c circuit (3 of 3) -> FUSE 24 FUSE 13
