Ford C-MAX II (2010-2015) drvr ikb rtn drvr ikb feed canister vent feed canister vent rtn Wiring diagram

AMBER IND BLU WIRE BLU/GRN WIRE BRN/BLU WIRE BRN/WHT WIRE CLOCK SPRING (TOP OF STEERING COLUMN) DASH) DRIVER AIR BAG (IN STEERING WHEEL) DRIVER SIDE AIR BAG (OUTER EDGE OF DRIVER SEAT BACK) DRIVER SIDE AIR CURTAIN (NEAR TOP OF DRIVER "C" PILLAR) DRVR AIR BAG 2 RTN DRVR AIR BAG 2 FEED DRVR IKB RTN DRVR IKB FEED CANISTER VENT FEED CANISTER VENT RTN ENS FRONT DRIVER DOOR SIDE IMPACT SENSOR (FRONT OF DRIVER DOOR) FRONT PASSENGER DOOR SIDE IMPACT SENSOR (FRONT OF PASSENGER DOOR) GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/YEL WIRE LEFT FRONT IMPACT SEVERITY SENSOR (LEFT FRONT OF ENGINE COMPT) NCA WIRE ORG YEL/ WIRE PAD IND PASS ADAPT LOAD LIMITER FEED PASS ADAPT LOAD LIMITER RTN PASS AIR BAG 2 FEED PASS AIR BAG 2 RTN PASS CURTAIN FEED PASS CURTAIN RTN PASS FRT CR SN RTN PASS FRT CR SN FEED DRVR FRT CR SN FEED DRVR FRT CR SN RTN PASS SIDE AIR FEED PASS SIDE AIR RTN DRVR SIDE AIR RTN DRVR SIDE AIR FEED PASSENGER AIR BAG (RIGHT SIDE OF DASH) PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR PASSENGER SIDE AIR BAG (OUTER EDGE OF PASSENGER SEAT BACK) PASSENGER SIDE AIR CURTAIN (NEAR TOP OF PASSENGER "C" PILLAR) RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) RIGHT FRONT IMPACT SEVERITY SENSOR (RIGHT FRONT OF ENGINE COMPT) RUN/START PAD INDICATOR SHORTING BAR SHORTING BAR IS STAGE 1 STAGE 2 TRACK POS TRACK POS DRVR CURTAIN FEED DRVR CURTAIN RTN VIO WIRE VIO/ GRY WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/ ORG WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
