Ford C-MAX II (2010-2015) driver seat rear height motor Wiring diagram
This page shows the only wiring diagram for the component.driver seat rear height motor, which is found in the car Ford C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat rear height motor (1 of 1)
BACK
BACK FORWARD FORWARD
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/GRN WIRE
DOWN
DRIVER SEAT DRIVER SEAT HORIZONTAL MOTOR RECLINER MOTOR
DRIVER SEAT FRONT HEIGHT MOTOR
DRIVER SEAT LUMBAR MOTOR
DRIVER SEAT REAR HEIGHT MOTOR
DRIVER SIDE FRONT SEAT CONTROL SWITCH
FRONT HEIGHT
FUSE JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HORIZONTAL
HOT AT ALL TIMES
LUMBAR
NOT USED
REAR HEIGHT
RECLINE
RED WIRE
UP DOWN
VIO WIRE
VIO/ORG WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component: -> Power seats circuit -> DRIVER SEAT REAR HEIGHT MOTOR
